Wiring diagrams for Mercedes-Benz GLK-class X204 facelift (2012-2015)

Automatic a/c circuit, w/o thermotronic Automatic a/c circuit, w/ thermotronic

Anti-lock brakes circuit

Anti-theft circuit

Front sam control module circuit Rear sam control module circuit

Data link connector circuit High/low bus circuit

Cooling fan circuit

Cruise control circuit

Heated mirrors circuit Rear defogger circuit

Electro hydraulic power steering circuit Power steering column circuit

Electronic suspension circuit

Stationary heater circuit

Wiring diagram engine performance 2.1l turbo diesel

Wiring diagram engine performance 3.5l

Backup lamps circuit Exterior lamps circuit Trailer light circuit

Ground distribution circuit

Headlights circuit

Horn circuit

Instrument cluster circuit Overhead console circuit

Courtesy lamps circuit Instrument illumination circuit

Driver"s memory seat circuit Memory mirrors circuit Passenger"s memory seat circuit Steering column memory circuit

Blind spot information system circuit Emergency call circuit Multifunction camera circuit Navigation circuit Parktronic circuit

Power distribution circuit

Automatic door locks circuit Keyless go system circuit

Automatic day/night mirror circuit Fold-back mirrors circuit

Heated seats circuit Heated steering wheel circuit Lumbar circuit Power seat circuit, w/ fully electric seat adjustment Power seat circuit, w/ partially electric seat adjustment Seat ventilation circuit

Power top/sunroof circuit

Power windows circuit Rear window sun shade circuit

Auto pilot system circuit Comand actuation circuit Dvd player circuit High definition tuner circuit Most data bus circuit Multimedia interface circuit Radio circuit Sound amplifier circuit

Shift interlock circuit

Charging circuit Starting circuit

Emergency seat belt tensioners circuit Supplemental restraint circuit Weight sensing system circuit

Transmission circuit

Trunk pull-down circuit

Seat belt warning circuit Tire pressure monitoring circuit

Headlamp washer circuit Wiper/washer circuit

ADDITIONAL BATTERY ANTI-LOCK BRAKES SYSTEM LEFT FANFARE HORN LEFT FRONT DOOR LOCK LEFT REAR DOOR LOCK ON-BOARD ELECTRICAL SYSTEM BATTERY RIGHT FANFARE HORN RIGHT FRONT DOOR LOCK RIGHT REAR DOOR LOCK SPRAY NOZZLE HEATER SPRAY NOZZLE HOSE HEATER

(RIGHT FRONT OF ENGINE ACTUATOR MOTOR AIR CONDITIONING, ENGINE CONTROLS SYSTEMS AIR DISTRIBUTION FLAP ACTUATOR BLOWER MOTOR CENTRAL LOCKING MOTOR CENTRAL MOTOR LOCKING COMAND FAN MOTOR COMBUSTION ENGINE, A/C W/ INTEGRATED CONTROL FAN MOTOR COMBUSTION ENGINE, AIR CONDITIONING W/ INTEGRATED CONTROL FAN MOTOR DEFROSTER VENT FLAP ACTUATOR MOTOR DIFFUSE FLAP ACTUATOR MOTOR DRIVER SEAT BACKREST INCLI- NATION ADJUST- MENT MOTOR DRIVER SEAT BACKREST INCLINATION ADJUSTMENT MOTOR DRIVER SEAT FORE/AFT ADJUSTMENT MOTOR DRIVER SEAT HEAD RESTRAINT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT INCLINATION ADJUSTMENT MOTOR ENGINE ACCESSORIES SYSTEM ENGINE CONTROLS SYSTEM ENGINE OIL PUMP VALVE EXHAUST GAS RECIRCULATION ACTUATOR FRESH AIR/ RECIRCULATION AIR FLAP ACTUATOR MOTOR FRESH AIR/ RECIRCULATION FLAP ACTUATOR MOTOR FRONT PASSE- NGER SEAT FORE/AFT ADJUSTMENT MOTOR FRONT PASSE- NGER SEAT HEIGHT ADJUSTMENT MOTOR FRONT PASSE- NGER SEAT INCLINATION ADJUSTMENT MOTOR FRONT PASSENGER SEAT BACKREST INCLINATION ADJUSTMENT MOTOR FRONT PASSENGER SEAT FORE/AFT ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEAD RESTRAINT ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER SEAT INCLINATION ADJUSTMENT MOTOR HEADLAMP RANGE ADJUSTMENT ACTUATOR MOTOR HIGH PRESSURE, RETURN PUMP MOTOR HORI MOTOR HOT W/ ENGINE INTAKE PORT SHUTOFF ACTUATOR MOTOR LEFT ACTIVE CURVE ILLUMINATION ACTUATOR MOTOR LEFT BLENDING AIR FLAP ACTUATOR LEFT CENTER AIR OUTLET FLAP ACTUATOR MOTOR LEFT DEFROSTER VENT FLAP ACTUATOR MOTOR LEFT FOOTWELL FLAP ACTUATOR MOTOR LEFT FRONT POWER WINDOW MOTOR LEFT REAR POWER WINDOW MOTOR LEFT SWITCHABLE ENGINE MOUNT OUTSIDE MIRROR FOLD-IN/ FOLD-OUT ELECTRIC MOTOR PANORAMIC SLIDING ROOF MOTOR POWER DISTRIBUTION, ENGINE CONTROLS SYSTEMS RADIATOR SHUTTERS ACTUATOR RAM AIR FLAP ACTUATOR MOTOR REAR BLEND AIR FLAP ACTUATOR MOTOR REAR BLOWER MOTOR REAR WINDOW ROLLER SUN BLIND MOTOR RIGHT ACTIVE CURVE ILLUMINATION ACTUATOR MOTOR RIGHT BLENDING AIR FLAP ACTUATOR RIGHT CENTER AIR OUTLET FLAP ACTUATOR MOTOR RIGHT DEFROSTER VENT FLAP ACTUATOR MOTOR RIGHT FOOTWELL FLAP ACTUATOR MOTOR RIGHT FRONT POWER WINDOW MOTOR RIGHT REAR POWER WINDOW MOTOR RIGHT SWITCHABLE ENGINE MOUNT ROOF MOTOR STARTING/CHARGING, ENGINE CONTROLS SYSTEMS STEERING COLUMN IN/OUT ADJUSTMENT MOTOR STEERING COLUMN UP/DOWN ADJUSTMENT MOTOR STEERING WHEEL VIBRATION MOTOR SUN BLIND MOTOR TAILGATE CENTRAL LOCKING MOTOR TAILGATE CONTROL ELECTRIC MOTOR TAILGATE WIPER MOTOR TANK CAP CENTRAL LOCKING MOTOR THROTTLE VALVE ACTUATOR VERT MOTOR W/ ENGINE MOUNT WIPER MOTOR

BLUETOOTH ANTENNA EMERGENCY CALL SYSTEM ANTENNA FM, AM, CL ANTENNA AMPLIFIER FM/TMC ANTENNA SPLITTER GLOBAL POSITIONING SYSTEM ANTENNA SPLITTER INTERIOR KEYLESS GO ANTENNA LEFT DOOR KEYLESS GO ANTENNA LEFT REAR DOOR KEYLESS GO ANTENNA MOBILE PHONE, STATIONARY HEATER RADIO REMOTE CONTROL ANTENNA SPLITTER MULTI-FUNCTION ANTENNA REAR WINDOW ANTENNA AMPLIFIER 1 REAR WINDOW ANTENNA FM ANTENNA AMPLIFIER RIGHT DOOR KEYLESS GO ANTENNA RIGHT REAR DOOR KEYLESS GO ANTENNA TRUNK KEYLESS GO ANTENNA TV 1, DAB BAND III ANTENNA

ACCEPT/TERMINATE PHONE CALL BUTTON AIR RECIRCULATION MODE BUTTON AUTOMATIC TRANSMISSION MODE BUTTON AUTOMATIC TRANSMISSION TRANSMISSION MODE BUTTON BACK BUTTON BACK, VOICE CONTROL SYSTEM OFF BUTTON BLOWER REGULATOR BLOWER REGULATOR A/C HOUSING BUTTON +, - SETTING OF SPECIFIC FUNCTIONS, VOLUME CONTROL CENTER HORNS BUTTON COMPASS DISPLAY BUTTON DELETE BUTTON DOWNHILL SPEED REGULATION BUTTON DRIVER TAILGATE CONTROL BUTTON DRIVER TRUNK LID/TAILGATE CONTROL BUTTON ECO START/ STOP FUNCTION BUTTON EMERGENCY CALL SYSTEM BUTTON EXHAUST GAS RECIRCULATION BYPASS FLAP ELECTRONIC VACUUM REGULATOR FRONT FOG LAMP BUTTON GARAGE DOOR OPENER BUTTON 1 GARAGE DOOR OPENER BUTTON 2 GARAGE DOOR OPENER BUTTON 3 HAZARD WARNING SYSTEM BUTTON LEFT FANFARE HORN SYSTEM BUTTON LEFT FRONT HEATED SEAT BUTTON LEFT FRONT SEAT VENTILATION BLOWER REGULATOR LEFT FRONT SEAT VENTILATION BUTTON LEFT MULTI-FUNCTION STEERING WHEEL BUTTON GROUP MB-INFO, BREAKDOWN ASSISTANCE BUTTON MUTE BUTTON OFFROAD PROGRAM BUTTON OK BUTTON PARKING SYSTEM BUTTON PARKTRONIC BUTTON PRESSURE REGULATOR VALVE REAR FOG LAMP BUTTON REAR FOG LIGHT BUTTON REAR HEAD RESTRAINTS BUTTON REAR WINDOW HEATER BUTTON REAR WINDOW ROLLER SUN BLIND BUTTON RIGHT FANFARE HORN SYSTEM BUTTON RIGHT FRONT HEATED SEAT BUTTON RIGHT FRONT SEAT VENTILATION BLOWER REGULATOR RIGHT FRONT SEAT VENTILATION BUTTON RIGHT MULTI-FUNCTION STEERING WHEEL BUTTON GROUP SCROLL FORWARD/ BACK BUTTON STATIONARY HEATER BUTTON STEERING WHEEL DOWNSHIFT BUTTON STEERING WHEEL UPSHIFT BUTTON SYSTEM SELECTION BUTTON TAILGATE CONTROL BUTTON TAILGATE KEYLESS GO BUTTON TRUNK LID RELEASE BUTTON TRUNK LID RELEASE/DRIVER TAILGATE CONTROL BUTTON VEHICLE DYNAMICS BUTTON VOICE CONTROL SYSTEM ON BUTTON W/O ECO START/ STOP BUTTON W/ ECO START/ STOP BUTTON

MULTI-FUNCTION CAMERA W/ BACKUP CAMERA W/ TIRE PRESSURE MONITOR W/ MULTI-FUNCTION CAMERA W/O MULTI-FUNCTION CAMERA

AUX JACK ELECTRICAL CONNECTOR COMPARTMENT SOCKET, DIAGNOSTIC CONNECTOR DRIVE TRAIN CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR DRIVER SEAT CONNECTOR BLOCK FRONT PASSENGER SEAT CONNECTOR BLOCK GLOVE BOX SOCKET LEFT VEHICLE FLOOR INTERIOR CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR LOAD COMPARTMENT SOCKET MEDIA INTERFACE ELECTRICAL CONNECTOR MOBILE PHONE ELECTRICAL CONNECTOR RIGHT VEHICLE FLOOR INTERIOR CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR SOCKET MICRO SWITCH TAXIMETER ELECTRICAL CONNECTOR TELEMATICS CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR TRACER WIRE CONNECTOR SLEEVE TRAILER SOCKET USB ELECTRICAL CONNECTOR VEHICLE DYNAMICS CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR VEHICLE FLOOR CHASSIS CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR

CDI CONTROL MODULE ELECTRONIC POWER STEERING CONTROL MODULE ELECTRONIC SELECTOR LEVEL MODULE CONTROL MODULE ELECTRONIC SELECTOR LEVER MODULE CONTROL MODULE FRONT SAM CONTROL MODULE UNIT W/ FUSE, RELAY MODULE FRONT SAM CONTROL MODULE W/ FUSE/ RELAY MODULE FUEL PUMP CONTROL MODULE LEFT FRONT DOOR CONTROL MODULE OVERHEAD CONTROL PANEL CONTROL MODULE PANORAMIC SLIDING ROOF CONTROL MODULE REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE RIGHT FRONT DOOR CONTROL MODULE

ADAPTIVE DAMPING CONTROL UNIT ADAPTIVE DAMPING SYSTEM CONTROL UNIT AMPLIFIER CONTROL UNIT AUTOMATIC AIR CONDITIONING CONTROL, OPERATING UNIT BACKUP CAMERA CONTROL UNIT COMAND CONTROL UNIT COMMAND CONTROL UNIT CONTROL UNIT) DC/AC CONVERTER CONTROL UNIT DIGITAL AUDIO BROADCASTING CONTROL UNIT DISTRONIC CONTROL UNIT DISTRONIC ELECTRIC CONTROLLER UNIT DISTRONIC ELECTRIC CONTROLLER UNIT, ELECTRO HYDRAULIC POWER STEERING DRIVER SEAT CONTROL UNIT DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT ELECTRIC STEERING LOCK CONTROL UNIT ELECTRIC TRANSMISSION OIL PUMP, TRANSMISSION OIL AUXILIARY PUMP CONTROL UNIT ELECTRICAL POWER STEERING CONTROL UNIT ELECTRONIC IGNITION SWITCH CONTROL UNIT ELECTRONIC SELECTOR LEVEL MODULE CONTROL UNIT ELECTRONIC STABILITY PROGRAM CONTROL UNIT ELECTRONIC TRANSMISSION CONTROL UNIT EMERGENCY CALL SYSTEM CONTROL UNIT FRONT PASSENGER SEAT CONTROL UNIT FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT FRONT SAM CONTROL UNIT W/ FUSE AND RELAY MODULE FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE FRONT SAM CONTROL UNIT W/ FUSE/RELAY MODULE FRONT SAM CONTROL UNIT W/FUSE, RELAY MODULE FUEL PUMP CONTROL UNIT FUEL PUMP SUPPLEMENTAL CONTROL RESTRAINT SYSTEM UNIT CONTROL UNIT FULLY INTEGRATED TRANSMISSION CONTROL CONTROL UNIT FULLY INTEGRATED TRANSMISSION CONTROL UNIT HEADLAMP CONTROL UNIT HEATER CONTROL UNIT INTERIOR PROTECTION, TOW-AWAY PROTECTION CONTROL UNIT KEYLESS-GO CONTROL UNIT LEFT FRONT AXLE DAMPING VALVE UNIT LEFT FRONT DOOR CONTROL UNIT LEFT FRONT LAMP UNIT LEFT REAR AXLE DAMPING VALVE UNIT LEFT REAR DOOR CONTROL UNIT LEFT REAR LAMP UNIT LEFT XENON LAMP CONTROL UNIT LEFT XENON LIGHT CONTROL UNIT MEDIA INTERFACE CONTROL UNIT OVERHEAD CONTROL PANEL CONTROL UNIT PANORAMIC SLIDING ROOF CONTROL UNIT PANORAMIC SLIDING ROOF ROLLER SUN BLIND DRIVE UNIT PARKTRONIC CONTROL UNIT RADIO CONTROL UNIT REAR AUTOMATIC AIR CONDITIONING OPERATING UNIT REAR SAM CONTROL UNIT W/ FUSE AND RELAY MODULE CIRCUIT 30 FUSE REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE CIRCUIT 30 FUSE REAR SAM CONTROL UNIT W/ FUSE/RELAY MODULE REAR SAM CONTROL UNIT W/FUSE, RELAY MODULE RIGHT FRONT AXLE DAMPING VALVE UNIT RIGHT FRONT DOOR CONTROL UNIT RIGHT FRONT LAMP UNIT RIGHT REAR AXLE DAMPING VALVE UNIT RIGHT REAR DOOR CONTROL UNIT RIGHT REAR LAMP UNIT RIGHT XENON LAMP CONTROL UNIT RIGHT XENON LIGHT CONTROL UNIT SDAR CONTROL UNIT/ HIGH DEFINITION TUNER SDAR CONTROL UNIT/HIGH DEFINITION TUNER SOUND SYSTEM AMPLIFIER CONTROL UNIT SPECIAL- PURPOSE VEHICLE MULTIFUNTION CONTROL UNIT STATIONARY HEATER UNIT STEERING COLUMN MODULE CONTROL UNIT STEERING COLUMN MODULE CONTROL UNIT, ELECTRONIC IGNITION SWITCH CONTROL UNIT, SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT TAILGATE CONTROL DRIVE UNIT TAILGATE CONTROL UNIT TILTING/ SLIDING ROOF DRIVE UNIT TIRE PRESSURE MONITOR CONTROL UNIT TRACTION SYSTEM HYDRAULIC UNIT TRAILER RECOGNITION CONTROL UNIT TRANSMISSION OIL AUXILIARY PUMP CONTROL UNIT UNIT) UPPER CONTROL PANEL CONTROL UNIT

FRONT ELECTRICAL PRE-FUSE BOX FUSE 1 FUSE 2 FUSE 3 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 9 FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 26 FUSE 27 FUSE 28 FUSE 29 FUSE 30 FUSE 32 FUSE 33 FUSE 34 FUSE 35 FUSE 36 FUSE 37 FUSE 38 FUSE 39 FUSE 40 RES FUSE 41 FUSE 42 FUSE 43 FUSE 44 FUSE 45 FUSE 46 FUSE 47 FUSE 48 RES FUSE 49 FUSE 50 FUSE 51 FUSE 52 RES FUSE 53 FUSE 54 FUSE 55 FUSE 57 FUSE 58 FUSE 59 FUSE 60 FUSE 61 FUSE 62 FUSE 63 FUSE 64 FUSE 65 FUSE 66 RES FUSE 67 FUSE 68 RES FUSE 69 FUSE 70 FUSE 71 FUSE 72 FUSE 73 FUSE 74 FUSE 75 FUSE 76 FUSE 77 FUSE 78 FUSE 79 RES FUSE 80 FUSE 81 FUSE 82 FUSE 83 FUSE 84 FUSE 85 FUSE 86 FUSE 87 FUSE 88 RES FUSE 89 FUSE 90 RES FUSE 91 RES FUSE 92 RES FUSE 150 FUSE 151 FUSE 152 FUSE 153 FUSE 154 FUSE 154 153 FUSE 155 FUSE 156 FUSE 156 161 FUSE 157 FUSE 158 160 FUSE 158 163 FUSE 159 FUSE 159 161 FUSE 160 162 FUSE 161 156 FUSE 162 FUSE 163 158 FUSE 164 THERMAL FUSE

AUXILIARY HEATER HEATING ELEMENT COOLANT THERMOSTAT HEATING ELEMENT FUEL PREHEATING SYSTEM HEATING ELEMENT MIRROR HEATER PTC HEATER BOOSTER REAR WINDOW HEATER STATIONARY HEATER RADIO REMOTE CONTROL RECEIVER STEERING WHEEL HEATER STEERING WHEEL HEATER HEATING ELEMENT VENT LINE HEATER ELEMENT W/ STATIONARY HEATER W/ STEERING WHEEL HEATER, AUTOMATIC LANE DETECTION WIPER PARK HEATER

ANTI-LOCK BRAKE SYSTEM INDICATOR LAMP ANTI-THEFT ALARM SYSTEM INDICATOR LAMP AUTOMATIC CHILD SEAT RECOGNITION AIR BAG OFF INDICATOR LAMP DIGITAL CLOCK, OUTSIDE TEMPERATURE INDICATOR ENGINE DIAGNOSIS INDICATOR LAMP FRONT FOG LAMPS INDICATOR LAMP FUEL LEVEL INDICATOR FUEL RESERVE INDICATOR LAMP GARAGE DOOR OPENER INDICATOR LAMP GEAR INDICATOR HIGH BEAM INDICATOR LAMP INDICATOR SWITCH INSTRUMENT PANEL PARKTRONIC WARNING INDICATOR LEFT BLIND SPOT ASSIST READINESS, WARNING INDICATOR LOW BEAM INDICATOR LAMP PARKING BRAKE INDICATOR SWITCH PREGLOW INDICATOR LAMP REAR FOG LAMP INDICATOR LAMP REAR PARKING SYSTEM WARNING INDICATOR RIGHT BLIND SPOT ASSIST READINESS, WARNING INDICATOR SERVICE BRAKE INDICATOR LAMP STANDING LAMPS INDICATOR LAMP SUPPLEMENTAL RESTRAINT SYSTEM INDICATOR LAMP

(W/ HEAD LAMP RANGE ADJUSTMENT FOR HALOGEN HEADLAMPS AMBIENT LAMP AUTOMATIC CHILD SEAT RECOGNITION AIR BAG OFF IND LAMP BACKUP LAMP BRAKE FLUID, PARKING BRAKE WARNING LAMP BRAKE SYSTEM WARNING LAMP BRAKE SYSTEM WARNING LAMP IND CENTER STOP LAMP COOLANT TEMPERATURE WARNING LAMP DISTRONIC WARNING LAMP ELECTRONIC STABILITY PROGRAM WARNING LAMP ESP OFF IND LAMP ESP/ASR OFF WARNING LAMP ESPA/ ASR OFF WARNING LAMP SERVICE BRAKE IND LAMP FOG LAMP GLOVE BOX LAMP) HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM LEFT FOG LAMP LEFT FRONT DOOR EXIT, WARNING LAMP LEFT FRONT FOOTWELL LAMP LEFT FRONT INTERIOR LAMP LEFT LICENSE PLATE LAMP LEFT LUGGAGE COMPARTMENT LAMP LEFT OUT SIDE MIRROR TURN SIGNAL LAMP LEFT OUTSIDE MIRROR TURN SIGNAL LAMP LEFT READING LAMP LEFT REAR DOOR EXIT, WARNING LAMP LEFT REAR READING LAMP LEFT SUN VISOR MIRROR LAMP LEFT TAILGATE AMBIENT LAMP, WARNING LAMP LEFT TURN SIGNAL IND LAMP MARKER LAMP REAR DOME LAMP REAR FOG LAMP REAR INTERIOR LAMP RIGHT FOG LAMP RIGHT FRONT DOOR EXIT, WARNING LAMP RIGHT FRONT FOOTWELL LAMP RIGHT FRONT INTERIOR LAMP RIGHT LICENSE PLATE LAMP RIGHT LUGGAGE COMPARTMENT LAMP RIGHT OUT SIDE MIRROR TURN SIGNAL LAMP RIGHT OUTSIDE MIRROR TURN SIGNAL LAMP RIGHT READING LAMP RIGHT REAR DOOR EXIT, WARNING LAMP RIGHT REAR READING LAMP RIGHT SUN VISOR MIRROR LAMP RIGHT TURN SIGNAL IND LAMP SEAT BELT WARNING LAMP SERVICE BRAKE IND LAMP SIDE MARKER LAMP STANDING/ PARKING LAMP STOP/ TAIL/ PARKING LAMP TIRE PRESSURE MONITOR WARNING LAMP TURN SIGNAL LAMP W/ INTERIOR LIGHTS PACKAGE XENON BULB W/ INTEGRATED IGNITION MODULE

COOLANT CIRCULATION PUMP DRIVER SEAT LUMBAR SUPPORT PNEUMATIC PUMP FRONT PASSENGER SEAT LUMBAR SUPPORT PNEUMATIC PUMP FUEL PUMP HEADLAMP CLEANING SYSTEM PUMP MULTICONTOUR SEAT PNEUMATIC PUMP STATIONARY HEATER FUEL PUMP WINDSHIELD WASHER SYSTEM PUMP WINDSHIELD WASHER SYSTEM PUMP, LEFT FRONT SIDE

ADDITIONAL BATTERY RELAY CIRCUIT 30 ADDITIONAL FUSE BACKUP RELAY CHASSIS CIRCUIT 87 RELAY CIRCUIT 15 RELAY CIRCUIT 87 RELAY ENERGIZED CUTOUT RELAY ENERGIZED DECOUPLING RELAY ENGINE CIRCUIT 87 RELAY FAN RELAY MODULE FANFARE HORN RELAY FUEL PUMP RELAY FUNCTION ADDITIONAL BATTERY RELAY HEATED REAR WINDOW RELAY HOT W/ ADDITIONAL BATTERY RELAY ENERGIZED HOT W/ CHASSIS CIRCUIT 87 RELAY ENERGIZED HOT W/ CIRCUIT 15 RELAY ENERGIZED HOT W/ ENGINE CIRCUIT 87 RELAY ENERGIZED HOT W/ QUIECENT CURRENT CUTOUT RELAY ENERGIZED HOT W/ QUIESCENT CURRENT CUTOUT RELAY HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED HOT W/ QUISCENT CURRENT CUTOUT RELAY ENERGIZED OIL COOLER FAN MOTOR RELAY QUIESCENT CURRENT CUTOUT RELAY QUIESCENT CURRENT CUTOUT RELAY ENERGIZED RELAY 1 ENERGIZED RELAY ENERGIZED SEAT ADJUSTMENT RELAY SECONDARY AIR INJECTION RELAY STARTER CIRCUIT 50 RELAY TAILGATE WINDSHIELD WIPER RELAY

ACCELERATOR PEDAL SENSOR BATTERY SENSOR BELT TENSION SENSOR BOOST PRESSURE SENSOR BRAKE VACUUM SENSOR CAMSHAFT HALL SENSOR CENTER LEFT FRONT PARKTRONIC DISTANCE SENSOR CENTER RIGHT FRONT PARKTRONIC DISTANCE SENSOR CHARGE AIR TEMPERATURE SENSOR CONDENSATION SENSOR FOR FUEL FILTER W/ HEATING ELEMENT COOLANT TEMPERATURE SENSOR CRANKSHAFT HALL SENSOR CYLINDER 3, 4 KNOCK SENSOR DISTRONIC RADAR SENSOR EMISSIONS SENSOR EVAPORATOR TEMPERATURE SENSOR EXHAUST BACK PRESSURE SENSOR FORWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR FRONT AXLE BRAKE PRESSURE SENSOR FRONT PRESSURE SENSOR FUEL PRESSURE SENSOR FUEL QUALITY SENSOR FUEL TANK PRESSURE SENSOR FUEL TANK PRESSURE, TEMPERATURE SENSOR FUEL TEMPERATURE SENSOR GEAR INDICATOR SENSOR HALL SENSOR HALL SENSOR 1 HALL SENSOR 2 HEATING ELEMENT TEMPERATURE SENSOR HOT FILM MASS AIR FLOW SENSOR INNER LEFT FRONT PARKTRONIC DISTANCE SENSOR INNER LEFT REAR PARKTRONIC DISTANCE SENSOR INNER RIGHT FRONT PARKTRONIC DISTANCE SENSOR INNER RIGHT REAR PARKTRONIC DISTANCE SENSOR INTAKE AIR TEMPERATURE SENSOR INTAKE MANIFOLD INTAKE AIR TEMPERATURE SENSOR INTERIOR HUMIDITY/ TEMPERATURE SENSOR INTERIOR TEMPERATURE SENSOR W/ INTEGRATED FAN INTERNAL TRANSMISSION SPEED RPM SENSOR KNOCK SENSOR CYLINDER 1, 2 KNOCK SENSOR CYLINDER 3, 4 LEFT ACTIVE CURVE ILLUMINATION POSITION SENSOR LEFT EXHAUST CAMSHAFT HALL SENSOR LEFT FRONT AXLE RPM SENSOR LEFT FRONT BODY LATERAL ACCELERATION SENSOR LEFT FRONT DOOR PRESSURE SENSOR LEFT FRONT LEVEL SENSOR LEFT FRONT TIRE PRESSURE SENSOR LEFT FRONTAL ACCELERATION SENSOR LEFT FUEL LEVEL INDICATOR SENSOR LEFT INTAKE CAMSHAFT HALL SENSOR LEFT KNOCK SENSOR LEFT NOX SENSOR LEFT REAR AXLE RPM SENSOR LEFT REAR BODY LATERAL ACCELERATION SENSOR LEFT REAR BUMPER INTELLIGENT RADAR SENSOR LEFT REAR BUMPER RADAR SENSOR LEFT REAR DOOR PRESSURE SENSOR LEFT REAR LEVEL SENSOR LEFT REAR TIRE PRESSURE SENSOR LEFT REAR WINDOW GLASS BREAKAGE SENSOR LEFT SIDE AIR BAG SENSOR LEFT TAILGATE CONTROL OBSTRUCTION SENSOR STRIP LEFT TEMPERATURE SENSOR UPSTREAM OF NOX STORAGE CATALYTIC CONVERTER LOW PRESSURE TURBOCHARGER BOOST PRESSURE SENSOR OIL TEMPERATURE SENSOR OUTER LEFT FRONT PARKTRONIC DISTANCE SENSOR OUTER LEFT REAR PARKTRONIC DISTANCE SENSOR OUTER RIGHT FRONT PARKTRONIC DISTANCE SENSOR OUTER RIGHT REAR PARKTRONIC DISTANCE SENSOR OUTPUT SHAFT RPM SENSOR OXYGEN SENSOR UPSTREAM OF CATALYTIC CONVERTER PANORAMIC SLIDING ROOF HALL SENSOR 1 PANORAMIC SLIDING ROOF HALL SENSOR 2 PRESSURE SENSOR DOWNSTREAM OF AIR FILTER PRESSURE SENSOR DOWNSTREAM OF THROTTLE VALVE RADIATOR SENSOR RADIATOR SENSOR FOR ENGINE DIAGNOSIS, RIGHT DAYTIME RUNNING LAMPS HEADLAMP RAIL PRESSURE SENSOR RAIN/LIGHT SENSOR REAR PRESSURE SENSOR REAR WINDOW GLASS BREAKAGE SENSOR REARWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR REFRIGERANT PRESSURE SENSOR RIGHT ACTIVE CURVE ILLUMINATION POSITION SENSOR RIGHT EXHAUST CAMSHAFT HALL SENSOR RIGHT FRONT AXLE RPM SENSOR RIGHT FRONT BODY LATERAL ACCELERATION SENSOR RIGHT FRONT BRAKE PAD WEAR SENSOR RIGHT FRONT BRAKE WEAR SENSOR RIGHT FRONT DOOR PRESSURE SENSOR RIGHT FRONT LEVEL SENSOR RIGHT FRONT TIRE PRESSURE SENSOR RIGHT FRONTAL ACCELERATION SENSOR RIGHT FUEL LEVEL INDICATOR SENSOR RIGHT INTAKE CAMSHAFT HALL SENSOR RIGHT NOX SENSOR RIGHT REAR AXLE RPM SENSOR RIGHT REAR BRAKE PAD WEAR SENSOR RIGHT REAR BRAKE WEAR SENSOR RIGHT REAR BUMPER INTELLIGENT RADAR SENSOR RIGHT REAR BUMPER RADAR SENSOR RIGHT REAR DOOR PRESSURE SENSOR RIGHT REAR LEVEL SENSOR RIGHT REAR TIRE PRESSURE SENSOR RIGHT REAR WINDOW GLASS BREAKAGE SENSOR RIGHT SIDE AIR BAG SENSOR RIGHT TAILGATE CONTROL OBSTRUCTION SENSOR STRIP RIGHT TEMPERATURE SENSOR UPSTREAM OF NOX STORAGE CATALYTIC CONVERTER SELECTION RANGE SENSOR SENSOR 1 SENSOR 2 STEERING ANGLE SENSOR SUN SENSOR TACHOMETER, BRIGHTNESS SENSOR TAILGATE CONTROL HALL SENSOR TAILGATE CONTROL POSITION SENSOR TEMPERATURE SENSOR TEMPERATURE SENSOR UPSTREAM OF DIESEL PARTICULATE FILTER TEMPERATURE SENSOR UPSTREAM OF TURBOCHARGER TOWING SENSOR BUTTON TRANSMISSION OIL TEMPERATURE SENSOR TURBINE WHEEL RPM SENSOR VIDEO, RADAR SENSOR SYSTEM VIDEO, RADAR SENSOR SYSTEM CONTROL UNIT W/ VIDEO, RADAR SENSOR SYSTEM CONTROL UNIT YAW RATE, LATERAL, LONGITUDINAL ACCELERATION SENSOR

BASS SPEAKER CENTER INSTRUMENT PANEL SPEAKER LEFT FRONT DOOR BASS SPEAKER LEFT FRONT DOOR SPEAKER LEFT REAR BASS SPEAKER LEFT REAR DOOR SPEAKER REAR BASS SPEAKER REAR BASS SPEAKER AMPLIFIER RIGHT FRONT DOOR BASS SPEAKER RIGHT FRONT DOOR SPEAKER RIGHT REAR BASS SPEAKER RIGHT REAR DOOR SPEAKER

ACCELERATE, SET SWITCH ADJUSTMENT SWITCH AUTOMATIC TRANSMISSION NEUTRAL POSITION SWITCH BRAKE FLUID LEVEL SWITCH CENTER REAR SEAT BELT BUCKLE SWITCH COMBINATION SWITCH DECELERATE, SET SWITCH DRIVER SEAT BELT BUCKLE RESTRAINT SYSTEM SWITCH DRIVER SEAT BELT BUCKLE RESTRAINT SYSTEMS SWITCH DRIVER SEAT EASY ENTRY SYSTEM LIMIT SWITCH DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SEAT PARTIALLY ELECTRIC SEAT ADJUSTMENT SWITCH DRIVER-SIDE POWER WINDOW, OUTSIDE MIRROR ADJUSTMENT SWITCH GROUP EXTERIOR LIGHTS SWITCH FLASHER/ HIGH BEAM SWITCH FRONT AXLE SWITCH OVER VALVE FRONT DOME LAMP SWITCH FRONT PASSENGER SEAT BELT BUCKLE RESTRAINT SYSTEM SWITCH FRONT PASSENGER SEAT EASY ENTRY SYSTEM LIMIT SWITCH FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH FRONT PASSENGER SEAT PARTIALLY ELECTRIC SEAT ADJUSTMENT SWITCH GLOVE BOX LAMP/ SWITCH HAZARD WARNING FLASHER SWITCH HEADLAMP FLASHER/ HIGH BEAM SWITCH LOW BEAM SWITCH HEADLAMP FLASHER/HIGH BEAM SWITCH ILLUMINATION SWITCH INSTRUMENT PANEL SWITCH GROUP INTAKE MANIFOLD RESONANCE FLAP SWITCH OVER VALVE INTAKE MANIFOLD SELECTOR DRUM SWITCH OVER VALVE INTERIOR LAMP AUTOMATIC FUNCTION SWITCH INTERIOR PROTECTION SWITCH LEFT ENGINE HOOD CONTACT SWITCH LEFT FRONT BACKREST ADJUSTMENT SWITCH LEFT FRONT DOOR CENTRAL LOCKING INTERIOR SWITCH LEFT FRONT MIRROR LAMP SWITCH LEFT FRONT POWER WINDOW SWITCH LEFT FRONT READING LAMP SWITCH LEFT FRONT SEAT ADJUSTMENT SWITCH GROUP LEFT FRONT SEAT FORE/AFT ADJUSTMENT SWITCH LEFT FRONT SEAT HEIGHT ADJUSTMENT SWITCH LEFT FRONT SEAT INCLINATION ADJUSTMENT SWITCH LEFT OUTSIDE MIRROR ADJUSTMENT SWITCH LEFT REAR POWER WINDOW SWITCH LEFT REAR READING SWITCH LEFT REAR SEAT BELT BUCKLE SWITCH LOW BEAM SWITCH OFF SWITCH OIL LEVEL CHECK SWITCH OUTSIDE MIRROR ADJUSTMENT SWITCH OUTSIDE MIRROR FOLD-IN/ FOLD-OUT SWITCH PASSENGER-SIDE POWER WINDOW SWITCH REAR DOME LAMP, SWITCH REAR SIDE WINDOW CHILD SAFETY LOCK SWITCH RESUME FROM MEMORY SWITCH RIGHT ENGINE HOOD CONTACT SWITCH RIGHT FRONT BACKREST ADJUSTMENT SWITCH RIGHT FRONT DOOR CENTRAL LOCKING INTERIOR SWITCH RIGHT FRONT MIRROR LAMP SWITCH RIGHT FRONT POWER WINDOW SWITCH RIGHT FRONT READING LAMP SWITCH RIGHT FRONT SEAT ADJUSTMENT SWITCH GROUP RIGHT FRONT SEAT FORE/AFT ADJUSTMENT SWITCH RIGHT FRONT SEAT HEIGHT ADJUSTMENT SWITCH RIGHT FRONT SEAT INCLINATION ADJUSTMENT SWITCH RIGHT OUTSIDE MIRROR ADJUSTMENT SWITCH RIGHT REAR POWER WINDOW SWITCH RIGHT REAR READING SWITCH RIGHT REAR SEAT BELT BUCKLE SWITCH ROTARY TUMBLER SWITCH STATIONARY HEATER SWITCH OVER VALVE STEERING COLUMN ADJUSTMENT SWITCH STOP LAMP SWITCH SWITCH ILLUMINATION TAILGATE CONTACT SWITCH TAILGATE EXTERNAL OPERATION SWITCH TILTING/ SLIDING ROOF SWITCH TRAILER HITCH LOCKING SWITCH TRUNK LID EMERGENCY OPENING SWITCH TURN SIGNAL LAMP SWITCH TURN SIGNAL LAMPS SWITCH WINDSHIELD WASHER SYSTEM FLUID LEVEL SWITCH WINDSHIELD WASHER SYSTEM SWITCH WIPE SWITCH WIPER SWITCH

ACTIVATED CHARCOAL FILTER SHUTOFF VALVE COOLANT PUMP SWITCHOVER VALVE DRIVER SEAT NECK-PRO HEAD RESTRAINT SOLENOID EXHAUST GAS RECIRCULATION COOLER BYPASS SWITCHOVER VALVE FRONT PASSENGER SEAT NECK-PRO HEAD RESTRAINT SOLENOID HEAT EXCHANGER SHUTOFF VALVE HIGH BEAM SOLENOID LEFT EXHAUST CAMSHAFT SOLENOID LEFT INTAKE CAMSHAFT SOLENOID OIL SPRAY NOZZLE SHUTOFF VALVE POWER STEERING PUMP QUANTITY CONTROL VALVE PURGE CONTROL VALVE QUANTITY CONTROL VALVE RIGHT EXHAUST CAMSHAFT SOLENOID RIGHT INTAKE CAMSHAFT SOLENOID SELECT LEVER POSITIONS R, P LOCKING SOLENOID SELECTOR LEVER POSITION R, P LOCKING SOLENOID SPEED-SENSITIVE POWER STEERING SOLENOID VALVE STATIONARY HEATER SWITCHOVER VALVE SWITCHOVER VALVE TORQUE CONVERTER LOCKUP CLUTCH CONTROL SOLENOID VALVE WORKING PRESSURE CONTROL SOLENOID VALVE

(OR RED/ WIRE BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/PNK WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/PNK WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/ORG WIRE BRN/PNK WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CAN G H PNK CAN G L WIRE CAN S H PNK CAN S L WIRE FLAT WIRE FLAT WIRE SIG FLAT WIRE GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/PNK WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/ORG WIRE GRY/PNK WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/GRN WIRE ORG/WHT WIRE PNK CAN S L WIRE PNK MIC 1+ WIRE PNK PNK WIRE PNK SIG WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PNK/GRN WIRE PNK/GRY WIRE PNK/RED WIRE PNK/WHT WIRE PNK/YEL WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/ORG WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE VL+ PNK HL+ WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/PNK WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/PNK WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE

1 CYL 1.8L TURBO 1.8L TURBO 2.1L TURBO DIESEL 3.5L 1.8L TURBO 3.5L 1.8L TURBO 3.5L 2.1L TURBO DIESEL 1.8L TURBO 3.5L 2.1L TURBO DIESEL EXCEPT 2.1L TURBO DIESEL 1.8L TURBO EXCEPT 1.8L TURBO 2 CYL 2.1L TURBO DIESEL 3 CYL 3.5L 4-CYL 30 RLS 31 LED (NOT (OR -1 +2 ABS IND. AC HOUSING, ACCEL/ DECEL/ SET SET ACOUSTIC TURN SIGNAL LIGHT FUNCTION CHECK AIR CONDITIONING SYSTEM AIR CONDITIONING SYSTEM POWER DISTRIBUTION SYSTEM AIR CONDITIONING, COOLING FANS SYSTEMS ALDW - ANT BT ANT GPS ANT GPS SHIELD GPS ANT NOT SHIELD NOT ANT SAT ANTI-THEFT SYSTEM ASS LED ASS OFF AUDIO COMAND CONTROL PANEL AUDIO GND AUDIO IN GND AUDIO IN R AUDIO IN SH AUDIO L+ AUDIO R- AUDIO SHIELD AUDIO-IN L AUDIO/ COMAND DISPLAY AUDIO/COMAND CONTROL PANEL AUDIO/COMAND CONTROLLER AUDIO/COMAND DISPLAY AUDIO/COMMAND CONTROL PANEL AUDIO/COMMAND DISPLAY AUTOMATIC DIMMING MIRROR AUX GND AUX L + AUX R + AUX SHIELD BATT + BBV HL BBV HR BBV VL BLS H BLS L BLS M BLS_H BLS_L BLS_M BLS_M CAN E L BOOST PRESSURE CONTROL FLAP PRESSURE TRANSDUCER BOOST PRESSURE CONTROL PRESSURE TRANSDUCER BOOST PRESSURE POSITIONER BSL L BSL R C-CLASS COUPE C-CLASS GLK-CLASS C-CLASS SEDAN, GLK- CLASS CABLE DET CAK BF CAK FA CAN A H CAN A L CAN B H CAN B L CAN C H CAN C L CAN E H CAN E H 31 CAN E L CAN H H CAN H L CAN I H CAN I L CAN L CAN-D H CAN-D L CAN-G H CAN-G L CAN-S H CAN-S L CHARGING CIRCUIT COMBUSTION AIR BLOWER COMPASS MODULE W/ DISPLAY COMPENSATOR/ CELLULAR TELEPHONE SYSTEM UMTS COMPENSATOR/CELLULAR TELEPHONE SYSTEM UMTS COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES, INSTRUMENT CLUSTER SYSTEMS COOLANT TEMPERATURE GAUGE COOLING FANS SYSTEM CORNERING ILLUMINATION CRADLE FOR NAVIGATION MODULE CRADLE NAVIGATION MODULE CRH OUT ANLG CRH OUT DTGL CRUISE CONTROL LEVER CRUISE CONTROL SYSTEM CRUISE CONTROL, ELECTRONIC POWER STEERING SYSTEMS CYLINDER 1 FUEL INJECTION CYLINDER 2 FUEL INJECTION CYLINDER 3 FUEL INJECTION CYLINDER 4 FUEL INJECTION CYLINDER 5 FUEL INJECTION CYLINDER 6 FUEL INJECTION D- D+ DATA 0+ DATA FOND DEFOGGER SYSTEM DF HL M DF HL S DF HR M DF HR S DF VL M DF VL S DF VR M DF VR S DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS, MIRROR SYSTEMS DRIVER AIR BAG SQUIB 1 DRIVER AIR BAG SQUIB 2 DRIVER KNEEBAG SQUIB DRIVER PELVIS AIR BAG SQUIB DRIVER SEAT BACKREST) DRIVER SEAT HEIGHT DRIVER SIDE AIR BAG SQUIB DRIVER SIDE FRONT DOOR INFRARED REMOTE CONTROL RECEIVER DS BF + DS FA + DS HL+ DS HR - DVD PLAYER E RDS EA LDS EKP-EC-U EKP-EC-V EKP-EC-W ELECTRO HYDRAULIC POWER STEERING ELECTROHYDRAULIC POWER STEERING ELECTRONIC POWER STEERING SYSTEM ELECTRONIC STABILITY PROGRAM CONTROL ELECTRONIC SUSPENSION, ELECTRONIC POWER STEERING SYSTEMS EMERGENCY CALL SYSTEM ETC+/- EV 1 EXCEPT 2.0L TURBO DIESEL EXCEPT 2.1L TURBO DIESEL EXCEPT 3.5L 3.5L 1.8L TURBO 2.1L TURBO DIESEL EXCEPT COUPE FA TANS FANFARE HORNS, AIR BAG CLOCK SPRING CONTACT FH H FH T FRONT CIGARETTE LIGHTER W/ ASHTRAY ILLUMINATION FRONT ELECTRICAL PREFUSE BOX FRONT PASSENGER AIR BAG SQUIB 1 FRONT PASSENGER AIR BAG SQUIB 2 FRONT PASSENGER PELVIS AIR BAG SQUIB FRONT PASSENGER SEAT HEIGHT FRONT PASSENGER SEAT OCCUPIED RECOGNITION FRONT PASSENGER SEAT OCCUPIED RECOGNITION, AUTOMATIC CHILD SEAT RECOGINITION FRONT PASSENGER SEAT OCCUPIED RECOGNITION, AUTOMATIC CHILD SEAT RECOGNITION FRONT PASSENGER SIDE BAG SQUIB FRONT VEHICLE INTERIOR POWER OUTLET FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUEL TANK GARAGE DOOR OPENER GLOW OUTPUT STAGE GLOW PLUG CYLINDER 1 GLOW PLUG CYLINDER 2 GLOW PLUG CYLINDER 3 GLOW PLUG CYLINDER 4 GLOW PLUG FLAME MONITOR GND CD GND MH 1 GPS FM GS BF + GS FA+ GS HL - GS HR - GSS BF GSS HL GSS HM GSS HR GSS, FA H SIDE HAND-SFREE HANDS FREE HANDS-FREE SYSTEM MICROPHONE HANDSFREE SYSTEM MICROPHONE HEADLAMP RANGE CONTROLLER HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HORNS SYSTEM HORI POTENTI- OMETER HORI POTENTIOMETER HORNS SYSTEM HOT AT ALL TIMES HOT IN ON OR START HOT IN RUN OR START HOT W/ HOT W/ CIRCUIT HR - HS 2 HTR 1 HTR 2 HV_MOT+ IGNITION COILS INFO LED INJ H INJ L INSIDE REAR VIEW MIRROR INSIDE REARVIEW MIRROR INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM INSTRUMENT CLUSTER, ANTI-THEFT SYSTEMS INSTRUMENT CLUSTER, POWER TOPS SYSTEMS INSTRUMENT CLUSTER, POWER TOPS SYSTEMS INSTRUMENT CLUSTER SYSTEM INSTRUMENT ILLUMINATION INSTRUMENT ILLUMINATION BRIGHTNESS CONTROL INSTRUMENT ILLUMINATION, INSTRUMENT ILLUMINATION BRIGHTNESS CONTROL INTERIOR PROTECTION RECEIVER IRS LED IRS-OFF KB FA- KTS SIG L SIDE LED 31 LEFT CENTER AIR OUTLET SYMBOL ILLUMINATION LEFT CORNERING ILLUMINATION LEFT DAYTIME RUNNING LAMPS HEADLAMP LEFT EXHAUST GAS RECIRCULATION POSITIONER LEFT FRONT BACKREST HEATED CUSHION LEFT FRONT BACKREST SEAT VENTILATION MOTORS LEFT FRONT DOOR DOOR HANDLE ILLUMINATION LEFT FRONT DOOR HANDLE ILLUMINATION LEFT FRONT DOOR HANDLE RECESS ILLUMINATION LEFT FRONT DOOR TWEETER LEFT FRONT KEYLESS GO DOOR HANDLE LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR LEFT FRONT SEAT CUSHION SEAT VENTILATION MOTORS LEFT FRONT SEAT SITTING SURFACE HEATED CUSHION LEFT FRONT SIDE AIR OUTLET SYMBOL ILLUMINATION LEFT INTERIOR PROTECTION TRANSMITTER LEFT OUTSIDE MIRROR LEFT REAR DISPLAY LEFT REAR DISPLAY, RIGHT REAR DISPLAY LEFT REAR DOOR DOOR HANDLE ILLUMINATION LEFT REAR DOOR HANDLE ILLUMINATION LEFT REAR DOOR HANDLE RECESS ILLUMINATION LEFT REAR EMERGENCY TENSIONING RETRACTOR SQUIB LEFT REAR KEYLESS GO GO DOOR HANDLE LEFT REAR SIDE BAG SQUIB LEFT REAR SURROUND LOUDSPEAKER LEFT REAR TWEETER LEFT TURN SIGNAL IND LIGHT LEFT WINDOW BAG SQUIB LH - LH+/ALDW+ LH-/ALDW- LIFT SIG LIN 1 LIN 2 LIN DATA LSP + LV_MOT+ LVDS N LVDS P MEMORY SYSTEM MIC 1+ MIC 2+ MIC - MK+ ML+ MLS H MLS V MOST DATA BUS CIRCUIT MOST IN MOST IN MOST MOST IN MOST 1 MOST OUT MOST OUT MOST MOT- MULTI-FUNCTION DISPLAY MULTIMEDIA INTERFACE CIRCUIT NAVI GND NAVI SHIELD NAVIGATION MODULE NAVIGATION SYSTEM NAVIGATION, CRUISE CONTROL SYSTEMS NAVIGATION, SOUND SYSTEMS NSL-L NSL-R NTC- NV_MOT+ NWG SIG NWSA 1 NWSE 2 OIL TEMP + OSS + OUTSIDE MIRROR FOLD IN/ FOLD OUT ELECTRIC MIRROR OVERHEAD CONTROL PANEL OVERHEAD CONTROL PANEL ELECTRONICS PARKING SYSTEM PG FA - PG, BF+ POWER DISTRIBUTION SYSTEM POWER TOPS SYSTEM POWER WINDOWS SYSTEM POWER WINDOWS, INSTRUMENT CLUSTER SYSTEMS QUIESCENT CURRENT RADIO W/ AUTO PILOT SYSTEM REAR AIR OUTLET SYMBOL ILLUMINATION REAR WINDOW INTERFERENCE SUPPRESSION CAPACITOR 1 REAR WINDOW INTERFERENCE SUPPRESSION CAPACITOR 2 REFRIGERANT COMPRESSOR REFRIGERANT COMPRESSOR W/ MAGNETIC CLUTCH RES+ RETURN LINE RFL L RFL R RIGHT CENTER AIR OUTLET SYMBOL ILLUMINATION RIGHT CORNERING ILLUMINATION RIGHT DAYTIME RUNNING LAMPS HEADLAMP RIGHT EXHAUST GAS RECIRCULATION POSITIONER RIGHT FRONT BACKREST HEATED CUSHION RIGHT FRONT BACKREST SEAT VENTILATION MOTORS RIGHT FRONT DOOR HANDLE ILLUMINATION RIGHT FRONT DOOR HANDLE RECESS ILLUMINATION RIGHT FRONT DOOR TWEETER RIGHT FRONT KEYLESS GO DOOR HANDLE RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR RIGHT FRONT SEAT CUSHION SEAT VENTILATION MOTORS RIGHT FRONT SEAT SITTING SURFACE HEATED CUSHION RIGHT FRONT SIDE AIR OUTLET SYMBOL ILLUMINATION RIGHT INTERIOR PROTECTION TRANSMITTER RIGHT OUTSIDE MIRROR RIGHT REAR DISPLAY RIGHT REAR DOOR DOOR HANDLE ILLUMINATION RIGHT REAR DOOR HANDLE ILLUMINATION RIGHT REAR DOOR HANDLE RECESS ILLUMINATION RIGHT REAR EMERGENCY TENSIONING RETRACTOR SQUIB RIGHT REAR KEYLESS GO DOOR HANDLE RIGHT REAR SIDE BAG SQUIB RIGHT REAR SURROUND LOUDSPEAKER RIGHT REAR TWEETER RIGHT TURN SIGNAL IND LIGHT RIGHT WINDOW AIR BAG SQUIB RSS AUS RSS EIN RTN LINE S GB S_GB 30 SB BF + SB FA + SB HL - SB HR - SEATS SYSTEM SHIELD BT SHIELD FM SHIELD FM 1 SHIELD GPS 1 SHIFT GATE SYMBOL ILLUMINATION SL L SOLID STATE SOS LED SOUND SYSTEM SOUND SYSTEMS SOUND, NAVIGATION SYSTEMS SS BF + SS FA + STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STEERING COLUMN MEMORY CIRCUIT STEERING COLUMN) STEERING WHEEL ELECTRONICS STR+ SUPPLEMENTAL RESTRAINT SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TAILGATE CONTROL MAGNETIC CLUTCH TAILGATE CONTROL WARNING BUZZER TAILGATE LOCKING ELEMENT TG L TG R TMC TMC TO CHASSIS CIRCUIT TO CIRCUIT TO SPARK PLUGS TRAILER HITCH RELEASE TRANSMISSION MODE DISPLAY TRANSMISSIONS SYSTEM TRAVEL DISTANCE DISPLAY TRUNK LID TRUNK, TAILGATE, FUEL DOORS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM STARTING/CHARGING SYSTEM UFS BF + UFS FA + USB D+ USB USB D- USB GND USED) VEHICLE INTERIOR POWER OUTLET VERT POTEN- TIO- METER VERT POTENTIOMETER VIDEO C VIDEO GND VIDEO N VIDEO P VIDEO Y VL - VOICE GND VOICE SHIELD VR+ W/ AIR OUTLET SYMBOL ILLUMINATION W/ AUTOMATIC TAILGATE W/ AVANTGARDE, ELEGANCE W/ CLASSIC W/ ECO START/ STOP FUNCTION W/ ETHANOL FUEL W/O ETHANOL FUEL W/ KEYLESS W/ KEYLESS GO SYSTEM W/O KEYLESS GO SYSTEM W/ KEYLESS GO W/O KEYLESS GO W/ MAGNETIC CLUTCH W/ MOBILE PHONE PRE INSTALLATION, UNIVERSAL INTERFACE W/ MOBILE PHONE PREINSTALLATION W/ UNIVERSAL INTERFACE W/ NAVIGATION W/ OVERHEAD CONTROL PANEL W/ CAN W/ PIEZO FUEL INJECTOR W/ REAR SIDE AIR BAG W/ SOUND SYSTEM W/ STRATIFIED CHARGE W/O STRATIFIED CHARGE W/ WEIGHT SENSING SYSTEM W/ XENON LAMPS W/O AIR OUTLET SYMBOL ILLUMINATION W/O AUTOMATIC TAILGATE W/O CAN W/ CAN W/O ECO START/ STOP FUNCTION W/O ECO START/ STOP FUNCTION W/ ECO START/ STOP FUNCTION W/O ECO START/STOP FUNCTION W/O ECO START/STOP FUNCTION W/ ECO START/STOP FUNCTION W/O KEYLESS W/O KEYLESS W/ KEYLESS W/O MAGNETIC CLUTCH W/O MOBILE PHONE PREINSTALLATION W/ UNIVERSAL INTERFACE W/O NAVIGATION W/O PIEZO FUEL INJECTOR W/O PIEZO FUEL INJECTOR W/ ECO START/STOP FUNCTION W/O ECO START/STOP FUNCTION W/O POWER GLASS TILTING /SLIDING SUNROOF W/O SMOKER PACKAGE W/O SOUND SYSTEM W/O TELEAID EMERGENCY CALL SYSTEM W/O XENON HEADLAMPS W/ XENON HEADLAMPS W/O XENON LAMPS WAKE-UP WARNING BUZZER WARNING SYSTEMS WB VL- WB VR+ WIPER/WASHER SYSTEM WS LED ZEU 2 ZUE 1 ZUE 3 ZUE 4 ZUE 5 ZUE 6 ZV ANT ZV-MOT +
