All around vision camera circuit for Mercedes-Benz GLE-class Coupe C292 (2015-2019)
All around vision camera circuit
360 DEGREE CAMERA CONTROL UNIT
BATTERY COMPARTMENT PREFUSE BOX
BLK WIRE
BLU WIRE
BRN WIRE
COMAND CONTROL UNIT (W/O AUDIO 20) RADIO (W/ AUDIO 20)
COMPUTER DATA LINES SYSTEM
FRONT END 360 DEGREE CAMERA
FUSE 6
GRN WIRE
LEFT SIDE 360 DEGREE CAMERA (IN LEFT REAR VIEW MIRROR)
MULTIPLE FUSE 2
NCA WIRE
ORG/ WIRE
REAR END 360 DEGREE CAMERA (BEHIND TAILGATE BADGE)
RED WIRE
RED/BLK WIRE
RELAY ENERGIZED
RIGHT SIDE 360 DEGREE CAMERA (IN RIGHT REAR VIEW MIRROR)
RX+ CD
RX+ EF
RX-
SHIELD
SHIELD CAM
TERM
YEL WIRE
YEL/WHT WIRE
