Active body control circuit for Mercedes-Benz GLE-class Coupe C292 (2015-2019)
Active body control circuit (1 of 2)
2.1L TURBO DIESEL
ACTIVE ROLL STABILIZATION CONTROL UNIT
ACTIVE ROLL STABILIZATION REAR AXLE DIRECTIONAL CONTROL VALVE
ACTIVE ROLL STABILIZATION REAR AXLE PRESSURE SENSOR 1
ACTIVE ROLL STABILIZATION REAR AXLE PRESSURE SENSOR 2
ACTIVE ROLL STABILIZATION THROTTLE VALVE
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
EXCEPT 2.1L TURBO DIESEL
FUSE 138
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT W/ CIRCUIT
REAR FUSE BOX
RED/BLK WIRE
SIG
SIG-HADRV
SIG-HAWV
SIG-SD
SIG-VAWV
WHT WIRE
Active body control circuit (2 of 2)
ACTIVE ROLL STABILIZATION CONTROL UNIT
ACTIVE ROLL STABILIZATION FRONT AXLE DIRECTIONAL CONTROL VALVE
ACTIVE ROLL STABILIZATION FRONT AXLE PRESSURE REGULATING VALVE
ACTIVE ROLL STABILIZATION FRONT AXLE PRESSURE SENSOR 1
ACTIVE ROLL STABILIZATION FRONT AXLE PRESSURE SENSOR 2
ACTIVE ROLL STABILIZATION LATERAL ACCELERATION SENSOR
ACTIVE ROLL STABILIZATION REAR AXLE PRESSURE REGULATING VALVE
ACTIVE ROLL STABILIZATION SAFETY VALVE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/WHT WIRE
SIG
SIG-QBS
SIG-SV
SIG-VADRV
VIO WIRE
VIO/BLK WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
