Mercedes-Benz GLE-class Coupe C167 (2019-2023) right trunk lid/liftgate control drive unit Wiring diagram
This page shows the only wiring diagram for the component.right trunk lid/liftgate control drive unit, which is found in the car Mercedes-Benz GLE-class Coupe C167 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right trunk lid/liftgate control drive unit (1 of 1)
A SIG
BLK/WHT WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
D-SIG
D-SIG HECKR
GRN/WHT WIRE
HECKD
NCA WIRE
REAR CENTRAL CONTROL UNIT
RED WIRE
RED/BLK WIRE
RIGHT TRUNK LID/LIFTGATE CONTROL DRIVE UNIT
SIG
TANK CAP CENTRAL LOCKING ACTUATOR
TRUNK LID/LIFTGATE CONTROL WARNING BUZZER
TRUNK LID/LIFTGATE EXTERNAL OPERATION BUTTON
TRUNK LID/LIFTGATE LOCK
TRUNK LID/LIFTGATE LOCKING ELEMENT
Go to component -> Trunk pull-down circuit (2 of 2) -> RIGHT TRUNK LID/LIFTGATE CONTROL DRIVE UNIT
