Mercedes-Benz GLE-class Coupe C167 (2019-2023) hand-detection sensor Wiring diagram
This page shows the only wiring diagram for the component.hand-detection sensor, which is found in the car Mercedes-Benz GLE-class Coupe C167 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hand-detection sensor (1 of 1)
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CAN LR H
CAN LR L
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE FUSE, RELAY MODULE
FLEX-E BM
FLEX-E BP
FUSE 203
GRN WIRE
GRN/BLU WIRE
HAND DETECTION SYSTEM CONTROL UNIT
HAND-DETECTION SENSOR
HEAD UNIT MULTI-FUNCTION STEERING WHEEL BUTTON GROUP
HORN CONTACT PLATE
HOT AT ALL TIMES
INSTRUMENT CLUSTER MULTI-FUNCTION STEERING WHEEL BUTTON GROUP
LIN
NCA WIRE
PNK WIRE
PNK/BLU WIRE
RED/WHT WIRE
SIG
STEERING COLUMN MODULE CONTROL UNIT (TOP OF STEERING COLUMN)
STEERING WHEEL DOWNSHIFT BUTTON
STEERING WHEEL ELECTRONICS
STEERING WHEEL HEATER
STEERING WHEEL UPSHIFT BUTTON
SUPPLEMENTAL RESTRAINTS SYSTEM
VIO/YEL WIRE
Go to component -> Electronic power steering circuit -> HAND-DETECTION SENSOR
