Mercedes-Benz GLE-class Coupe C167 (2019-2023) drive control unit Wiring diagram
This page shows the only wiring diagram for the component.drive control unit, which is found in the car Mercedes-Benz GLE-class Coupe C167 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drive control unit (1 of 1)
3.0L TURBO HYBRID
4.0L TURBO HYBRID
AMBIANCE ILLUMINATION CONTROL UNIT
BLK/GRY WIRE
BLU WIRE
BRN WIRE
CENTER REAR SEAT BELT BUCKLE SWITCH
CENTER, RIGHT REAR PASSENGER COMPARTMENT SEAT BELT BUCKLES
CLIMATE CONTROL OPERATING UNIT
CYLINDER 1+2 IGNITION COIL
CYLINDER 3+4 IGNITION COIL
DC/DC CONVERTER CONTROL UNIT
DRIVE CONTROL UNIT
DRIVER-SIDE OUTSIDE AMBIENT LIGHTING
ENGINE START/STOP BUTTON
FRONT PASSENGER SEAT CONTROL UNIT
FRONT PASSENGER SEAT SIDE PRE-SAFEAPULSE SQUIB
FRONT PASSENGER SIDE BAG SQUIB
HEAD UNIT/ INSTRUMENT CLUSTER DISPLAY CLUSTER
HEAD-UP DISPLAY
HIGH-VOLTAGE PTC HEATER
INNER RIGHT FRONT SEAT TRIM ELEMENT AMBIENT LIGHTING
INSTRUMENT CLUSTER CONTROL UNIT
INTERIOR TEMPERATURE SENSOR
LEFT FRONT FOOTWELL LAMP
LEFT REAR SEAT BELT BUCKLE SWITCH
LEFT REAR SIDE BAG SQUIB
ME-SFI (ME) CONTROL UNIT
NCA WIRE
REAR CUP HOLDER
REAR SEAT HEATERS CONTROL UNIT
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
RIGHT REAR CUSHIONBAG SQUIB
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR FOOTWELL LAMP
RIGHT REAR PASSENGER COMPARTMENT SIDE WINDOW ROLLER SUNBLIND CONTROL UNIT
RIGHT REAR SIDE BAG SQUIB
SEATS SWITCH GROUP (RIGHT LOAD COMPARTMENT)
STEERING COLUMN MODULE CONTROL UNIT
Go to component -> Ground distribution circuit (6 of 6) -> DRIVE CONTROL UNIT
