Front ventilation & heated seat circuit, coupe for Mercedes-Benz GLC-class X254 (2022-2024)
Front ventilation & heated seat circuit, coupe (1 of 2)
***
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/VIO WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER SEAT CONTROL UNIT
FUSE 302
FUSE 305
HOT AT ALL TIMES
LEFT FRONT BACKREST SEAT VENTILATION MOTORS
LEFT FRONT DOOR CONTROL UNIT
LEFT FRONT SEAT ADJUSTABLE SEAT CUSHION LENGTH HEATER PAD
LEFT FRONT SEAT ADJUSTMENT SWITCH GROUP
LEFT FRONT SEAT BACKREST HEATER PAD
LEFT FRONT SEAT CLIMATE CONTROL SWITCH GROUP
LEFT FRONT SEAT CUSHION HEATER PAD
LEFT FRONT SEAT CUSHION SEAT VENTILATION MOTORS
NCA WIRE
PASSENGER-SIDE A-PILLAR FUSE BOX
RED WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
SIG 31
SIG GND
VIO WIRE
Front ventilation & heated seat circuit, coupe (2 of 2)
***
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/VIO WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER SEAT CONTROL UNIT
FUSE 306
FUSE 406
HOT AT ALL TIMES
NCA WIRE
PASSENGER-SIDE A-PILLAR FUSE BOX
REAR FUSE, RELAY MODULE
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RIGHT FRONT BACKREST SEAT VENTILATION MOTORS
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT SEAT ADJUSTABLE SEAT CUSHION LENGTH HEATER PAD
RIGHT FRONT SEAT ADJUSTMENT SWITCH GROUP
RIGHT FRONT SEAT BACKREST HEATER PAD
RIGHT FRONT SEAT CLIMATE CONTROL SWITCH GROUP
RIGHT FRONT SEAT CUSHION HEATER PAD
RIGHT FRONT SEAT CUSHION SEAT VENTILATION MOTORS
SIG GND
VIO WIRE
