Mercedes-Benz GLC-class X254 (2022-2024) Ground distribution circuit, coupe
Ground distribution circuit, coupe (1 of 6)
BRN WIRE
ELECTRIC COOLANT PUMP
ENGINE FUSE, RELAY MODULE
KEYLESS-GO CONTROL UNIT
LEFT FANFARE HORN
LEFT FRONT LAMP UNIT
LEFT LUGGAGE COMPARTMENT LAMP
LEFT LUGGAGE COMPARTMENT REAR BACKREST RELEASE BUTTON
LEFT REAR BACKREST INCLINATION SWITCH
LEFT REAR BACKREST RELEASE ACTUATOR
LEFT REAR LAMP UNIT
LUGGAGE COMPARTMENT SOCKET
PARKING SYSTEM CONTROL UNIT
REAR SAM CONTROL UNIT
RIGHT FANFARE HORN
RIGHT FRONT LAMP UNIT
RIGHT REAR LAMP UNIT
SOUND SYSTEM AMPLIFIER CONTROL UNIT
SPRAY NOZZLE HOSE HEATER
TAILGATE CONTROL UNIT
TRAILER RECOGNITION CONTROL UNIT
TRAILER SOCKET (7-PIN)
TRANSMISSION OIL COOLING COOLANT CIRCULATION PUMP
WHT WIRE
WIPER MOTOR
Ground distribution circuit, coupe (2 of 6)
BRN WIRE
BRN/GRN WIRE
CENTER STOP LAMP
INNER LEFT REAR LAMP UNIT
INNER RIGHT REAR LAMP UNIT
LEFT INTERIOR CAN (CAN B) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR
LEFT LICENSE PLATE LAMP
LEFT OUTER REAR BUMPER INTEGRATED RADAR SENSOR
LEFT OUTER REAR BUMPER RADAR SENSOR
LEFT TRUNK LID/LIFTGATE AMBIENT LAMP, WARNING LAMP
NCA WIRE
PERIPHERALS CAN (CAN PER) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
REAR SWITCHING MODULE
RIGHT LICENSE PLATE LAMP
RIGHT LUGGAGE COMPARTMENT LAMP
RIGHT LUGGAGE COMPARTMENT REAR BACKREST RELEASE BUTTON
RIGHT OUTER REAR BUMPER INTEGRATED RADAR SENSOR
RIGHT OUTER REAR BUMPER RADAR SENSOR
TAILGATE WIPER MOTOR
TANK CAP CENTRAL LOCKING ACTUATOR
TIRE PRESSURE MONITOR CONTROL UNIT
TRUNK LID/LIFTGATE EXTERNAL OPERATION BUTTON
TRUNK LID/LIFTGATE LOCK
YEL WIRE
Ground distribution circuit, coupe (3 of 6)
ACTIVE BRAKE ASSIST CONTROLLER UNIT
BATTERY DISCONNECT SWITCH RELAY
BLK WIRE
BRN WIRE
ELECTRIC BRAKE SYSTEM ELECTRICAL CONNECTOR
FAN MOTOR
FRONT CENTER CONSOLE CUP HOLDER AMBIANCE ILLUMINATION
FRONT SAM CONTROL UNIT
FUEL PUMP CONTROL UNIT
HERMES CONTROL UNIT
LEFT FRONT DOOR CONTROL UNIT
LOWER LEFT CENTER CONSOLE AMBIENT LIGHTING
LOWER RIGHT CENTER CONSOLE AMBIENT LIGHTING
MONO MULTI-FUNCTION CAMERA
NCA WIRE
PASSENGER SIDE ENGINE HOOD CONTACT SWITCH
RIGHT FRONT BRAKE WEAR SENSOR
RIGHT REAR BACKREST INCLINATION SWITCH
RIGHT REAR BACKREST RELEASE ACTUATOR
RIGHT REAR BRAKE WEAR SENSOR
UPPER LEFT CENTER CONSOLE AMBIENT LIGHTING
UPPER RIGHT CENTER CONSOLE AMBIENT LIGHTING
USER INTERFACE CAN (CAN HMI) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR
VOLTAGE DIP LIMITER
YEL WIRE
Ground distribution circuit, coupe (4 of 6)
AUDIO/ COMAND DISPLAY
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
CIRCUIT 31 POTENTIAL DISTRIBUTOR 1
CIRCUIT 31 POTENTIAL DISTRIBUTOR 2
CYLINDER 1 IGNITION COIL
CYLINDER 2 IGNITION COIL
CYLINDER 3 IGNITION COIL
CYLINDER 4 IGNITION COIL
DIAGNOSTIC CONNECTOR
DIGITAL INSTRUMENT CLUSTER FAN MOTOR
DRIVER SIDE ENGINE HOOD CONTACT SWITCH
ELECTRIC PARKING BRAKE SWITCH
ELECTRONIC STABILITY PROGRAM CONTROL UNIT
INSTRUMENT CLUSTER
KEYLESS GO START/STOP BUTTON
LEFT FRONT FOOTWELL AMBIANCE ILLUMINATION LAMP
LOW TEMPERATURE CIRCUIT CIRCULATION PUMP 1
ME-SFI (ME) CONTROL UNIT
STEERING COLUMN MODULE CONTROL UNIT
STOWAGE COMPARTMENT ILLUMINATION
TOP OF ENGINE)
Ground distribution circuit, coupe (5 of 6)
AMBIANCE ILLUMINATION CONTROL UNIT
AUDIO/COMAND CONTROL PANEL
BRN WIRE
DRIVETRAIN CONTROL UNIT
ELECTRONIC IGNITION SWITCH CONTROL UNIT
FRONT PASSENGER SEAT CONTROL UNIT
FRONT PASSENGER SEAT LUMBAR SUPPORT ELECTROPNEUMATIC CONTROLLER UNIT
FRONT PASSENGER SEAT LUMBAR SUPPORT PNEUMATIC PUMP
FRONT PASSENGER SIDE BAG SQUIB
HEAD UNIT
MOBILE PHONE CRADLE CONTROL UNIT
OVERHEAD CONTROL PANEL CONTROL UNIT
PARK PAWL CAPACITOR
RAIN/LIGHT SENSOR W/ ADDITIONAL FUNCTIONS
REAR USB ELECTRICAL CONNECTOR
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT ILLUMINATED DOOR SILL MOLDING
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR FOOTWELL ILLUMINATION AMBIANCE ILLUMINATION (LED)
SLIDING ROOF CONTROL MODULE
Ground distribution circuit, coupe (6 of 6)
AC HOUSING,
BLK WIRE
BRN WIRE
CLIMATE CONTROL OPERATING UNIT
CLIMATE CONTROL UNIT
DEDICATED SHORT-RANGE COMMUNICATIONS CONTROL UNIT
DRIVER SEAT CONTROL UNIT
DRIVER SEAT LUMBAR SUPPORT PNEUMATIC PUMP
DRIVER SIDE BAG SQUIB
DRIVER'S SEAT LUMBAR SUPPORT ELECTROPNEUMATIC CONTROLLER UNIT
ELECTRICAL POWER STEERING CONTROL UNIT
FRONT PASSENGER FOOTWELL SOCKET
FRONT SAM CONTROL UNIT
LEFT FRONT ILLUMINATED DOOR SILL MOLDING
LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
LEFT REAR DOOR CONTROL UNIT
LEFT REAR FOOTWELL ILLUMINATION AMBIANCE ILLUMINATION (LED)
PTC HEATER BOOSTER
RIGHT FRONT FOOTWELL AMBIANCE ILLUMINATION
UPPER CONTROL PANEL CONTROL UNIT
