High/low bus circuit, coupe for Mercedes-Benz GLC-class X254 (2022-2024)

AUDIO/COMAND AUDIO/COMAND DISPLAY BLK WIRE BLK/WHT WIRE BRN WIRE CAN A H CAN A L CAN HMI H CAN HMI L HEAD UNIT (CENTER OF DASH) INSTRUMENT CLUSTER LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR MOBILE PHONE CRADLE CONTROL UNIT RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT TIRE PRESSURE MONITOR CONTROL UNIT USER INTERFACE CAN (CAN HMI) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR WHT WIRE YEL WIRE YEL/WHT WIRE

BRN WIRE BRN/RED WIRE CAN B H CAN B L CAN HMI H CAN HMI L CAN PER H CAN PER L CAN-D H CAN-D L DIAGNOSTIC CONNECTOR ELECTRICAL POWER STEERING CONTROL UNIT ELECTRONIC IGNITION SWITCH CONTROL UNIT ELECTRONIC STABILITY PROGRAM CONTROL UNIT FLEX-E BM FLEX-E BP FLEX-E BP PNK FLEX-E BM WIRE GRN WIRE GRN/WHT WIRE GRY WIRE GRY/WHT WIRE HERMES CONTROL UNIT PARKING SYSTEM CONTROL UNIT (LEFT SIDE OF LUGGAGE COMPT) PNK FLEX-E BM WIRE PNK WIRE STEERING COLUMN MODULE CONTROL UNIT YEL WIRE YEL/WHT WIRE

ACTIVE BRAKE ASSIST CONTROLLER UNIT BLU WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE CAN PER H CAN PER L DRIVETRAIN CONTROL UNIT (RIGHT FRONT FOOTWELL) FLEX-E BM FLEX-E BP GRN WIRE GRN/WHT WIRE LEFT FRONT LAMP UNIT LEFT OUTER REAR BUMPER INTEGRATED RADAR SENSOR LEFT OUTER REAR BUMPER RADAR SENSOR MONO MULTI-FUNCTION CAMERA PERIPHERALS CAN (CAN PER) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR PNK WIRE RIGHT FRONT LAMP UNIT RIGHT OUTER REAR BUMPER INTEGRATED RADAR SENSOR RIGHT OUTER REAR BUMPER RADAR SENSOR

AMBIANCE ILLUMINATION CONTROL UNIT BLU WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE CAN B H CAN B L CLIMATE CONTROL UNIT DRIVER SEAT CONTROL UNIT FRONT PASSENGER SEAT CONTROL UNIT FRONT SAM CONTROL UNIT KEYLESS-GO CONTROL UNIT LEFT FRONT DOOR CONTROL UNIT LEFT INTERIOR CAN (CAN B) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR LEFT REAR DOOR CONTROL UNIT OVERHEAD CONTROL PANEL CONTROL UNIT REAR SAM CONTROL UNIT RIGHT FRONT DOOR CONTROL UNIT RIGHT REAR DOOR CONTROL UNIT SLIDING ROOF CONTROL MODULE TAILGATE CONTROL UNIT

BLU WIRE BLU/WHT WIRE BRN WIRE ELECTRIC COOLANT PUMP FUEL PUMP CONTROL UNIT FULLY INTEGRATED TRANSMISSION CONTROL UNIT LOW TEMPERATURE CIRCUIT CIRCULATION PUMP 1 ME-SFI (ME) CONTROL UNIT SOUND SYSTEM AMPLIFIER CONTROL UNIT TOP OF ENGINE) WHT WIRE
