Mercedes-Benz GLC-class X253 (2015-2019) steering column in/out adjustment motor, hall sensor Wiring diagram
This page shows the only wiring diagram for the component.steering column in/out adjustment motor, hall sensor, which is found in the car Mercedes-Benz GLC-class X253 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering column in/out adjustment motor, hall sensor (1 of 1)
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER SEAT CONTROL UNIT
FLEXRAY BP
FUSE 305
FUSE 329
FUSE 406
GRN WIRE
HOT AT ALL TIMES
HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED
LEFT FRONT DOOR CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT SWITCH GROUP
M+ (-)
MEMORY 2 SWITCH
MEMORY 3 SWITCH
MEMORY FUNCTION SWITCH MEMORY 1 SWITCH
PNK FLEXRAY BM WIRE
REAR FUSE, RELAY MODULE
RED WIRE
RIGHT A-PILLAR FUSE BOX
SIG
STEERING COLUMN ADJUSTMENT, STEERING WHEEL HEATER SWITCH
STEERING COLUMN IN/OUT ADJUSTMENT MOTOR, HALL SENSOR
STEERING COLUMN MODULE CONTROL UNIT
STEERING COLUMN UP/DOWN ADJUSTMENT MOTOR, HALL SENSOR
STEERING COLUMN)
VIO WIRE
VIO/BLK WIRE
Go to component -> Steering column memory circuit -> STEERING COLUMN IN/OUT ADJUSTMENT MOTOR, HALL SENSOR
