Mercedes-Benz GLC-class X253 (2015-2019) special-purpose vehicle multi-function control unit Wiring diagram
This page shows the only wiring diagram for the component.special-purpose vehicle multi-function control unit, which is found in the car Mercedes-Benz GLC-class X253 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram special-purpose vehicle multi-function control unit (1 of 1)
30 LIN
ALARM SIREN
ATA (EDM)/TOWING SENSOR/ INTERIOR MOTION SENSOR CONTROL UNIT
ATA (EDW) FUNCTION IND
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
CAN B H
CAN B L
CAN HMI H
CAN HMI L
COMPUTER DATA LINES SYSTEM
EMERGENCY ALARM SYSTEM "CANCEL" BUTTON
EMERGENCY ALARM SYSTEM "TRIGGER" BUTTON
EMERGENCY ALARM SYSTEM CANCEL BUTTON RESISTOR
FUSE 202
FUSE 312
FUSE 326
FUSE 432
HOT AT ALL TIMES
HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED
INSTRUMENT CLUSTER
INTERIOR LAMP AUTOMATIC FUNCTION BUTTON
INTERIOR PROTECTION SWITCH
LEFT FRONT DOOR INTERIOR PROTECTION SENSOR
LEFT FUSE, RELAY MODULE
LEFT REAR INTERIOR PROTECTION SENSOR
MULTI-FUNCTION DISPLAY
OFF
OVERHEAD CONTROL PANEL CONTROL UNIT
POWER DISTRIBUTION SYSTEM
REAR FUSE, RELAY MODULE
REAR WINDOW GLASS BREAKAGE SENSOR
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT A-PILLAR FUSE BOX
RIGHT FRONT DOOR INTERIOR PROTECTION SENSOR
RIGHT REAR INTERIOR PROTECTION SENSOR
SPECIAL-PURPOSE VEHICLE MULTI-FUNCTION CONTROL UNIT
UPPER CONTROL PANEL CONTROL UNIT
YEL WIRE
YEL/WHT WIRE
