Mercedes-Benz GLC-class X253 (2015-2019) right trunk lid/ liftgate ambient lamp, warning lamp Wiring diagram
This page shows the only wiring diagram for the component.right trunk lid/ liftgate ambient lamp, warning lamp, which is found in the car Mercedes-Benz GLC-class X253 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right trunk lid/ liftgate ambient lamp, warning lamp (1 of 1)
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAN B H
CAN B L RBA-1
COMPUTER DATA LINES SYSTEM
EXCEPT CONVERTIBLE
FUSE 302
FUSE 303
FUSE 406
FUSE 408
FUSE 465
FUSE 466
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
KRL L HL
KRL R HR
LEFT LUGGAGE COMPARTMENT LAMP
LEFT REAR FOOTWELL LAMP
LEFT TRUNK LID/ LIFTGATE AMBIENT LAMP, WARNING LAMP
PWR-1
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
RED WIRE
RIGHT A-PILLAR FUSE BOX
RIGHT LUGGAGE COMPARTMENT LAMP
RIGHT REAR FOOTWELL LAMP
RIGHT TRUNK LID/ LIFTGATE AMBIENT LAMP, WARNING LAMP
SIG HD
TRUNK LID/ LIFTGATE EXTERNAL OPERATION SWITCH
Go to component -> Courtesy lamps circuit (4 of 6) -> RIGHT TRUNK LID/ LIFTGATE AMBIENT LAMP, WARNING LAMP
