Mercedes-Benz GLC-class X253 (2015-2019) right frontal acceleration sensor Wiring diagram
This page shows the only wiring diagram for the component.right frontal acceleration sensor, which is found in the car Mercedes-Benz GLC-class X253 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right frontal acceleration sensor (1 of 1)
BF L DR (-)
BF L FPS (-)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/PNK WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
CAN H L
COMPUTER DATA LINES SYSTEM
CRASH ANALOG
CRASH LH (+)
CRASH RF (+)
DRIVER SIDE BAG SQUIB
EXCEPT CONVERTIBLE
FRONT PASSENGER ANCHOR FITTING TENSIONER SQUIB
FRONT SAM CONTROL UNIT
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
GRY/YEL WIRE
LEFT HEAD BAG SQUIB
LEFT REAR EMERGENCY TENSIONING RETRACTOR SQUIB
LEFT REAR ENGINE HOOD LIFTER
LEFT SIDE BAG SENSOR
LEFT WINDOW BAG SQUIB
ME-SFI (ME) CONTROL UNIT
PNK/BLK WIRE
RBA-1
RIGHT FRONTAL ACCELERATION SENSOR
RIGHT HEAD BAG SQUIB
RIGHT REAR EMERGENCY TENSIONING RETRACTOR SQUIB
RIGHT REAR ENGINE HOOD LIFTER
RIGHT REAR SIDE BAG SQUIB
RIGHT WINDOW BAG SQUIB
SB BF PS (-)
SB DR (-)
SB RR (+)
SB RR (-) SIG
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT
TNSG RTR DR (+)
TNSG RTR LR (+)
TNSG RTR RR (-)
USA
USA W/ SEAT OCCUPANCY RECOGNITION W/O SEAT OCCUPANCY RECOGNITION
VIO WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WB L (+)
WB R (-)
WHT/GRN WIRE
YEL WIRE
Go to component -> Supplemental restraint circuit (1 of 4) -> RIGHT FRONTAL ACCELERATION SENSOR
