Mercedes-Benz GLC-class X253 (2015-2019) right backrest release/ inclination microswitch Wiring diagram
This page shows the only wiring diagram for the component.right backrest release/ inclination microswitch, which is found in the car Mercedes-Benz GLC-class X253 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right backrest release/ inclination microswitch (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLU/BLK WIRE
BRN WIRE
FRONT PASSENGER SEAT BACKREST INCLINATION ADJUSTMENT MOTOR
FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR
FRONT PASSENGER SEAT PARTIALLY ELECTRIC SEAT ADJUSTMENT SWITCH
FUSE 403
HOLDER, POWER OUTLET RELAY ENERGIZED
RBA-1
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT BACKREST RELEASE/ INCLINATION MICROSWITCH
SIG
W/ BACKREST RELEASE W/O BACKREST RELEASE
YEL/GRN WIRE
Go to component -> Power seat circuit, w/o comfort seats -> RIGHT BACKREST RELEASE/ INCLINATION MICROSWITCH
