Mercedes-Benz GLC-class X253 (2015-2019) rearward automatic dimming mirror light sensor Wiring diagram
This page shows the only wiring diagram for the component.rearward automatic dimming mirror light sensor, which is found in the car Mercedes-Benz GLC-class X253 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rearward automatic dimming mirror light sensor (1 of 1)
ALARM SIREN
AMBIENT LAMP
ATA (EDW)/TOWING SENSOR/ INTERIOR MOTION SENSOR CONTROL UNIT
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/BLK WIRE
CAN A H
CAN A L
COMPUTER DATA LINES SYSTEM
FORWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR
FUSE 202
GARAGE DOOR OPENER
GARAGE DOOR OPENER BUTTON 1
GARAGE DOOR OPENER BUTTON 2
GARAGE DOOR OPENER BUTTON 3
GARAGE DOOR OPENER INDICATOR LAMP
GRN WIRE
GRY WIRE
HANDS-FREE SYSTEM MICROPHONE
HEAD UNIT
HOT AT ALL TIMES
INSIDE REAR VIEW MIRROR
INSIDE REAR VIEW MIRROR DIMMING
LEFT FRONT DOOR INTERIOR PROTECTION SENSOR
LEFT FUSE, RELAY MODULE
LEFT READING LAMP
LEFT REAR INTERIOR PROTECTION SENSOR
MIC 1 IN+
MIC 2 IN+
NCA WIRE
ORG/ WIRE
PNK WIRE
REAR WINDOW GLASS BREAKAGE SENSOR
REARWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR INTERIOR PROTECTION SENSOR
RIGHT READING LAMP
RIGHT REAR INTERIOR PROTECTION SENSOR
SHIELD
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Overhead console circuit (2 of 2) -> REARWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR
