Mercedes-Benz GLC-class X253 (2015-2019) rba rba-1 Wiring diagram
This page shows the only wiring diagram for the component.rba rba-1, which is found in the car Mercedes-Benz GLC-class X253 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rba rba-1 (1 of 1)
BLK WIRE
BRN WIRE
BRN/RED WIRE
CAN B H RBA-1
CAN B L
COC
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE SWITCH
FLEXRAY 1 BM
FLEXRAY 1 BP
FOOTWELL ILLUMINATION SWITCH
FRONT CENTER CONSOLE CUP HOLDER AMBIANCE ILLUMINATION
FRONT CIGARETTE LIGHTER W/ ASHTRAY ILLUMINATION
FRONT SAM CONTROL UNIT (LEFT END OF DASH)
FUSE 200
GRN WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HEADLAMP FLASHER/ HIGH BEAM SWITCH
HOT AT ALL TIMES
LDS SGN 1 PNK WIRE
LDS SGN 2
LDS SGN 3
LEFT FUSE, RELAY MODULE
LEFT LUGGAGE COMPARTMENT REAR BACKREST RELEASE BUTTON
PEDAL OPERATION MONITOR SWITCH
PNK WIRE
PNK/GRN WIRE
PWR-1
RBA RBA-1
RED WIRE
RIGHT LUGGAGE COMPARTMENT REAR BACKREST RELEASE BUTTON
STEERING COLUMN MODULE CONTROL UNIT
TWO-WAY RADIO SWITCH
VEHICLE INTERIOR POWER OUTLET
VIO WIRE
W/ SMOKER'S PACKAGE
W/O SMOKER'S PACKAGE
YEL WIRE
Go to component -> Instrument illumination circuit (1 of 3) -> RBA RBA-1
