Mercedes-Benz GLC-class X253 (2015-2019) panoramic sliding roof control module Wiring diagrams
This page contains all the electrical diagrams for the component. panoramic sliding roof control module, in which he is found in the car Mercedes-Benz GLC-class X253 (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram panoramic sliding roof control module (1 of 3)
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
CAN I H
CAN I L
CAN PER H
CAN PER L
DRIVETRAIN CONTROL UNIT
ENGINE SOUND CONTROL UNIT
FUEL PUMP CONTROL UNIT
FULLY INTEGRATED TRANSMISSION CONTROL UNIT
GRN WIRE
GRN/WHT WIRE
INTELLIGENT SERVO MODULE FOR DIRECT SELECT
ME-SFI (ME) CONTROL UNIT
PANORAMIC SLIDING ROOF CONTROL MODULE
PNK WIRE
PNK/WHT WIRE
SLIDING ROOF CONTROL MODULE
TRANSMISSION OIL AUXILIARY OIL PUMP CONTROL UNIT
W/ PANORAMIC SLIDING SUNROOF
W/O PANORAMIC SLIDING SUNROOF
YEL WIRE
YEL/WHT WIRE
Go to component -> High/low bus circuit (5 of 6) -> PANORAMIC SLIDING ROOF CONTROL MODULE
Wiring diagram panoramic sliding roof control module (2 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FRONT SAM CONTROL UNIT
FUSE 312
FUSE 317
GRN WIRE
GRY WIRE
HALL SENSOR 1
HALL SENSOR 2
HOT AT ALL TIMES
HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED
MOT-
MOTOR
OVERHEAD CONTROL PANEL CONTROL UNIT
PANORAMIC SLIDING ROOF CONTROL MODULE
PANORAMIC SLIDING ROOF CONTROL UNIT
PANORAMIC SLIDING ROOF HALL SENSOR 1
PANORAMIC SLIDING ROOF HALL SENSOR 2
PANORAMIC SLIDING ROOF MOTOR
PANORAMIC SLIDING ROOF ROLLER SUN BLIND DRIVE UNIT
RBA-1
RED WIRE
RED/WHT WIRE
RIGHT A-PILLAR FUSE BOX
ROOF SWITCH
VIO WIRE
Go to component -> Panoramic roof circuit -> PANORAMIC SLIDING ROOF CONTROL MODULE
Wiring diagram panoramic sliding roof control module (3 of 3)
ADAPTIVE DAMPING SYSTEM (ADS) CONTROL UNIT
AIRMATIC CONTROL UNIT
AUDIO/COMAND CONTROL PANEL
AUDIO/COMAND DISPLAY
BLK WIRE
BOOSTER BLOWER ELECTRONIC BLOWER REGULATOR
CONTROL UNIT)
DRIVER SEAT CONTROL UNIT
DRIVER SEAT CONTROL UNIT, DRIVER SEAT HEATER CONTROL UNIT
DRIVER-SIDE INSTRUMENT PANEL BUTTON GROUP
DRIVETRAIN CONTROL UNIT, ME-SFI (ME) CONTROL UNIT
ELECTRIC BRAKE CONTROL ELECTRICAL CONNECTOR
ENGINE SOUND CONTROL UNIT
FROM FUSE 325 (DIAGRAM 6 OF 6)
FROM VEHICLE INTERIOR PREFUSE BOX (DIAGRAM 1 OF 6)
FRONT SAM CONTROL UNIT
FRONT SEAT HEATER CONTROL UNIT, FRONT PASSENGER SEAT CONTROL UNIT
FUSE 302
FUSE 303
FUSE 304
FUSE 305
FUSE 306
FUSE 308
FUSE 309
FUSE 310
FUSE 311
FUSE 312
FUSE 315
FUSE 316
FUSE 317
FUSE 318
FUSE 319
FUSE 320
FUSE 322
FUSE 323
FUSE 324
FUSE 325
FUSE 326
FUSE 327
FUSE 328
FUSE 329
FUSE 330
FUSE 331
FUSE 332
FUSE 333
FUSE 334
FUSE 336
FUSE 337
FUSE 338
FUSE 339
FUSE 340
FUSE 341
HEAD UNIT
HEAD-UP DISPLAY
INTELLIGENT SERVO MODULE FOR DIRECT SELECT
LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
LEFT REAR DOOR CONTROL UNIT, REAR CONTROL UNIT
MONO MULTI-FUNCTION CAMERA
MULTI-MEDIA CONNECTION UNIT
OVERHEAD CONTROL PANEL CONTROL UNIT
OVERHEAD CONTROL PANEL CONTROL UNIT, RAIN/LIGHT SENSOR W/ ADDITIONAL FUNCTIONS
PANORAMIC SLIDING ROOF CONTROL MODULE
PARKING SYSTEM CONTROL UNIT (IF EQUIPPED)
RADAR SENSORS CONTROL UNIT
REAR AIR CONDITIONING OPERATING UNIT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
SLIDING ROOF CONTROL MODULE
STATIONARY HEATER UNIT
STEERING COLUMN MODULE CONTROL UNIT
STEREO MULTI-FUNCTION CAMERA
SUPPLEMENTAL RESTRAINT SYSTEM
TIRE PRESSURE MONITOR CONTROL UNIT
TO FUSE 324 (DIAGRAM 6 OF 6)
TOUCHPAD
W/ ACTIVE PARK ASSIST
W/ AUTONOMOUS INTELLIGENT CRUISE CONTROL PLUS
W/ PRE- SAFE
Go to component -> Power distribution circuit (6 of 6) -> PANORAMIC SLIDING ROOF CONTROL MODULE
