Mercedes-Benz GLC-class X253 (2015-2019) left front door rotary tumbler switch Wiring diagrams

AWL BLU WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM GRN WIRE LEFT FRONT DOOR AMBIANCE ILLUMINATION LEFT FRONT DOOR CONTROL UNIT LEFT FRONT DOOR EXIT, WARNING LAMP LEFT FRONT DOOR EXTERIOR DOOR HANDLE ILLUMINATION LEFT FRONT DOOR HANDLE AMBIANCE ILLUMINATION LEFT FRONT DOOR HANDLE ILLUMINATION LEFT FRONT DOOR LOCK LEFT FRONT DOOR ROTARY TUMBLER SWITCH LL BU LL RD RED WIRE RED/BLU WIRE RIGHT FRONT DOOR AMBIANCE ILLUMINATION RIGHT FRONT DOOR EXIT, WARNING LAMP RIGHT FRONT DOOR EXTERIOR DOOR HANDLE ILLUMINATION RIGHT FRONT DOOR HANDLE AMBIANCE ILLUMINATION RIGHT FRONT DOOR HANDLE ILLUMINATION RIGHT FRONT DOOR LOCK RIGHT FRONT DOOR ROTARY TUMBLER SWITCH SIG TBA TIB W/ INTERIOR LIGHTS PACKAGE, DRIVING SCHOOL PACKAGE W/ AMBIANCE ILLUMINATION YEL WIRE YEL/WHT WIRE

BBV VR BCL SW DR(-) BLK WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH BRAKE FLUID, PARKING BRAKE INDICATOR LAMP BRAKE SYSTEM WARNING LAMP BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE CAN B H CAN B L CAN B L RBA-1 CAN H L CAN HMI H CAN HMI L COMPUTER DATA LINES SYSTEM DRIVER SEAT BELT BUCKLE SWITCH ELECTRIC PARKING BRAKE SWITCH ELECTRONIC STABILITY PROGRAM CONTROL UNIT ENGINE COMPARTMENT PREFUSE BOX FRONT SAM CONTROL UNIT FUSE 1 FUSE 200 FUSE 208 FUSE 316 FUSE 465 FUSE 466 GRN WIRE GRY/BLU WIRE GRY/GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LEFT FRONT DOOR CONTROL UNIT LEFT FRONT DOOR LOCK LEFT FRONT DOOR ROTARY TUMBLER SWITCH LEFT FUSE, RELAY MODULE MULTI-FUNCTION DISPLAY NCA WIRE PWR-1 REAR FUSE, RELAY MODULE REAR SAM CONTROL UNIT RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT A-PILLAR FUSE BOX RIGHT FRONT BRAKE WEAR SENSOR RIGHT REAR BRAKE WEAR SENSOR SEAT BELT WARNING LAMP SIG SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT SW 1 SW 2 SW 3 SW 4 VIO WIRE VIO/WHT WIRE WHT/GRY WIRE YEL WIRE YEL/WHT WIRE
