Panoramic roof circuit for Mercedes-Benz GLC-class Coupe C253 facelift (2019-2023)
Panoramic roof circuit
BLK WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
CAN B L RBA-1
COMPUTER DATA LINES SYSTEM
FRONT SAM CONTROL UNIT
FUSE 309
FUSE 312
FUSE 317
GRN WIRE
GRY WIRE
HALL SENSOR 1
HALL SENSOR 2
HOT AT ALL TIMES
HOT W/ BATTERY DISCONNECT SWITCH RELAY ENERGIZED
MOT-
MOTOR
OVERHEAD CONTROL PANEL CONTROL UNIT
PANORAMIC SLIDING ROOF CONTROL MODULE
PANORAMIC SLIDING ROOF ROLLER SUN BLIND DRIVE UNIT
PASSENGER-SIDE A-PILLAR FUSE BOX
RED WIRE
RED/WHT WIRE
W/ FUEL CELL RETROFITTING
W/O FUEL CELL RETROFITTING
