Front ventilation & heated seat circuit, w/o memory for Mercedes-Benz GLC-class Coupe C253 facelift (2019-2023)
Front ventilation & heated seat circuit, w/o memory
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/VIO WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FRONT SEAT HEATER CONTROL UNIT
FUSE 302
FUSE 306
FUSE 406
GRY WIRE
GRY/BLK WIRE
HOT W/ BATTERY DISCONNECT SWITCH RELAY ENERGIZED
LEFT FRONT BACKREST SEAT VENTILATION MOTORS
LEFT FRONT DOOR CONTROL UNIT
LEFT FRONT SEAT ADJUSTABLE CUSHION LENGTH HEATER PAD
LEFT FRONT SEAT BACKREST HEATER PAD
LEFT FRONT SEAT CLIMATE CONTROL SWITCH GROUP
LEFT FRONT SEAT CUSHION HEATER PAD
LEFT FRONT SEAT CUSHION VENTILATION MOTORS
PASSENGER-SIDE A-PILLAR FUSE BOX
REAR FUSE, RELAY MODULE
RED WIRE
RED/BLU WIRE
RED/VIO WIRE
RIGHT FRONT BACKREST SEAT VENTILATION MOTORS
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT SEAT ADJUSTABLE CUSHION LENGTH HEATER PAD
RIGHT FRONT SEAT BACKREST HEATER PAD
RIGHT FRONT SEAT CLIMATE CONTROL SWITCH GROUP
RIGHT FRONT SEAT CUSHION HEATER PAD
RIGHT FRONT SEAT CUSHION VENTILATION MOTORS
SHZ(+)
VIO WIRE
W/ SEAT HEATER, SEAT CLIMATE CONTROL
