Blind spot information system circuit for Mercedes-Benz GLC-class Coupe C253 facelift (2019-2023)
Blind spot information system circuit
BLK WIRE
BRN WIRE
BRN/RED WIRE
BSM
BSM GND
CAN B H
CAN B L
CAN PER H
CAN PER L
COMPUTER DATA LINES SYSTEM
FUSE 302
FUSE 406
GRN WIRE
GRN/WHT WIRE
HECKD
HOT AT ALL TIMES
LEFT FRONT DOOR CONTROL UNIT
LEFT OUTER REAR BUMPER INTEGRATED RADAR SENSOR
LEFT OUTSIDE MIRROR
PASSENGER-SIDE A-PILLAR FUSE BOX
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
RED WIRE
RED/BLU WIRE
RIGHT FRONT DOOR CONTROL UNIT
RIGHT OUTER REAR BUMPER INTEGRATED RADAR SENSOR
RIGHT OUTSIDE MIRROR
