Anti-theft circuit for Mercedes-Benz GLC-class Coupe C253 facelift (2019-2023)
Anti-theft circuit
ALARM SIREN
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
CAN B H
CAN B L
CAN HMI H
CAN HMI L
COMPUTER DATA LINES SYSTEM
DRIVER SIDE ENGINE HOOD CONTACT SWITCH
FRONT SAM CONTROL UNIT
FUSE 312
FUSE 318
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT REAR WINDOW GLASS BREAKAGE SENSOR
LIN
OVERHEAD CONTROL PANEL CONTROL UNIT
PASSENGER SIDE ENGINE HOOD CONTACT SWITCH
PASSENGER-SIDE A-PILLAR FUSE BOX
REAR WINDOW GLASS BREAKAGE SENSOR
RED WIRE
RIGHT REAR WINDOW GLASS BREAKAGE SENSOR
SIG
UPPER CONTROL PANEL CONTROL UNIT
YEL WIRE
YEL/WHT WIRE
