Mercedes-Benz GLC-class Coupe C253 facelift (2019-2023) overhead panel control module Wiring diagram
This page shows the only wiring diagram for the component.overhead panel control module, which is found in the car Mercedes-Benz GLC-class Coupe C253 facelift (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram overhead panel control module (1 of 1)
2.0L TURBO
ALL-WHEEL DRIVE CONTROL UNIT
AUGMENTED REALITY CAMERA
BLUE LIGHT SEPARATION POINT
BRN WIRE
CELLULAR TELEPHONE SYSTEM ANTENNA AMPLIFIER/ COMPENSATOR
DRIVETRAIN CONTROL UNIT
ELECTRONIC IGNITION SWITCH CONTROL UNIT
ENGINE RUN-ON FEATURE CONNECTING POINT
FLASHING LIGHT ELECTRICAL CONNECTOR
FRONT PASSENGER SEAT CONTROL UNIT
FRONT PASSENGER SEAT LUMBAR ELECTROPNEUMATIC CONTROLLER UNIT
FRONT PASSENGER SEAT LUMBAR SUPPORT PNEUMATIC PUMP
FRONT PASSENGER SEAT PARTIALLY ELECTRIC SEAT ADJUSTMENT SWITCH
FRONT PASSENGER SIDE BAG SQUIB
FRONT SEAT HEATER CONTROL UNIT
GERMAN ASSOCIATION OF THE AUTOMOTIVE INDUSTRY CONNECTING POINT
HAND MOTION SENSOR
LEFT REAR FOOTWELL LAMP
NCA WIRE
NOX SENSOR CONTROL UNIT DOWNSTREAM OF SCR CATALYTIC CONVERTER
OVERHEAD PANEL CONTROL MODULE
PANORAMIC SLIDING ROOF CONTROL MODULE
PARK PAWL CAPACITOR
RAIN LIGHT SENSOR W/ ADDITIONAL FUNCTIONS
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT ILLUMINATED DOOR SILL MOLDING
RIGHT FRONT MULTICONTOUR SEAT CONTROL UNIT
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR FOOTWELL ILLUMINATION AMBIANCE ILLUMINATION (LED)
RIGHT TABLET PC ELECTRICAL CONNECTOR
SLIDING ROOF CONTROL MODULE
SPECIAL SIGNAL SYSTEM OPERATING UNIT
STARTER ALTERNATOR
TRUNK LID/REAR END DOOR FLASHING LIGHT
TWO-WAY RADIO MAIN SWITCH CONNECTING POINT
VIDEO SYSTEM
Go to component -> Ground distribution circuit (5 of 6) -> OVERHEAD PANEL CONTROL MODULE
