Emergency seat belt tensioners circuit for Mercedes-Benz GLC-class Coupe C253 (2016-2019)
Emergency seat belt tensioners circuit
BRN WIRE
CAN HMI H
CAN HMI L
COMPUTER DATA LINES SYSTEM
FUSE 330
FUSE 332
FUSE 411
FUSE 443
HOT AT ALL TIMES
HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED
LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
REAR FUSE, RELAY MODULE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT A-PILLAR FUSE BOX
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
YEL WIRE
YEL/WHT WIRE
