Charging circuit for Mercedes-Benz GLC-class Coupe C253 (2016-2019)
Charging circuit
ALTERNATOR
BATTERY SENSOR
BLK WIRE
BLK/BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
CAN HMI H
CAN HMI L
COMPUTER DATA LINES SYSTEM
DVD CHANGER CHARGING BUTTON
ENGINE COMPARTMENT PREFUSE BOX
FRONT SAM CONTROL UNIT
GRN WIRE
GRN/WHT WIRE
INSTRUMENT CLUSTER
LIN 1
LIN RBA-1
ME-SFI (ME) CONTROL MODULE
MULTI-FUNCTION DISPLAY
NCA WIRE
ON-BOARD ELECTRICAL SYSTEM BATTERY
RED WIRE
STARTING CIRCUIT
UPPER CONTROL PANEL CONTROL UNIT
YEL WIRE
YEL/WHT WIRE
