Parktronic circuit for Mercedes-Benz GLC-class Coupe C253 (2016-2019)

AUDIO/COMAND CONTROL PANEL BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BRN WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE CAN A H CAN A L CAN B H CAN B L CENTER LEFT FRONT PARKING SYSTEM DISTANCE SENSOR CENTER LEFT REAR PARKING SYSTEM DISTANCE SENSOR CENTER RIGHT FRONT PARKING SYSTEM DISTANCE SENSOR CENTER RIGHT REAR PARKING SYSTEM DISTANCE SENSOR COC COMPUTER DATA LINES SYSTEM DATA WE 2 DRIVER-SIDE INSTRUMENT PANEL BUTTON GROUP DRIVETRAIN CONTROL UNIT ELECTRONIC STABILITY PROGRAM CONTROL UNIT FEED FEED WE 2 FLEXRAY 1 BM FLEXRAY 1 BP FLEXRAY 1/2 BM FLEXRAY 1/2 BP FRONT SAM CONTROL UNIT FUSE 323 FUSE 331 FUSE 339 GND WE 2 GRN WIRE HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED INNER LEFT FRONT PARKING SYSTEM DISTANCE SENSOR INNER LEFT REAR PARKING SYSTEM DISTANCE SENSOR INNER RIGHT FRONT PARKING SYSTEM DISTANCE SENSOR INNER RIGHT REAR PARKING SYSTEM DISTANCE SENSOR LEFT LOWER CONTROL PANEL LIN LIN 1 OUTER LEFT FRONT PARKING SYSTEM DISTANCE SENSOR OUTER LEFT REAR PARKING SYSTEM DISTANCE SENSOR OUTER RIGHT FRONT PARKING SYSTEM DISTANCE SENSOR OUTER RIGHT REAR PARKING SYSTEM DISTANCE SENSOR PARKING SYSTEM BUTTON PARKING SYSTEM CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT) PNK WIRE RBA-1 REAR PARKING SYSTEM INDICATOR RED/WHT WIRE RED/YEL WIRE RIGHT A-PILLAR FUSE BOX RIGHT LOWER CONTROL PANEL W/ AIRMATIC, AUTONOMOUS INTELLIGENT CRUISE CONTROL PLUS W/O AIRMATIC, AUTONOMOUS INTELLIGENT CRUISE CONTROL PLUS WHT WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE
