Blind spot information system circuit for Mercedes-Benz GLC-class Coupe C253 (2016-2019)
Blind spot information system circuit
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
CAN PER H
CAN PER L
COMPUTER DATA LINES SYSTEM
FUSE 302
FUSE 406
FUSE 452
GRY WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/ VEHICLE INTERIOR TERMINAL 15 RELAY ENERGIZED
LEFT BLIND SPOT ASSIST READINESS, WARNING INDICATOR
LEFT FRONT DOOR CONTROL UNIT
LEFT OUTER REAR BUMPER INTEGRATED RADAR SENSOR
LEFT OUTSIDE MIRROR
REAR FUSE, RELAY MODULE
RED WIRE
RED/BLU WIRE
RIGHT A-PILLAR FUSE BOX
RIGHT BLIND SPOT ASSIST READINESS, WARNING INDICATOR
RIGHT FRONT DOOR CONTROL UNIT
RIGHT OUTER REAR BUMPER INTEGRATED RADAR SENSOR
RIGHT OUTSIDE MIRROR
TA B (+)
TA W (+)
VIO WIRE
VIO/WHT WIRE
