Car Wiring Diagrams for Headlights circuit, w/ static led headlamps for Mercedes-Benz GLC-class Coupe C253 (2016-2019)

BLK WIRE BLU/BRN WIRE BRN WIRE BRN/RED WIRE CAN B H CAN B L CAN H H CAN H L CAN HMI H CAN HMI L COC COMPUTER DATA LINES SYSTEM ELECTRIC PARKING BRAKE SWITCH ELECTRONIC STABILITY PROGRAM CONTROL UNIT (LEFT REAR OF ENGINE COMPT) ENGINE FUSE, RELAY MODULE EXTERIOR LIGHTS SWITCH FRONT FOG LAMP INDICATOR LAMP FRONT SAM CONTROL UNIT (LEFT END OF DASH) FUSE 128 FUSE 200 FUSE 208 GRN WIRE GRY/BLU WIRE HEADLAMP RANGE CONTROLLER HIGH BEAM INDICATOR LAMP HOT AT ALL TIMES HOT W/ ENGINE COMPARTMENT TERMINAL 15 RELAY ENERGIZED INSTRUMENT CLUSTER LDS SGN 1 LDS SGN 2 LDS SGN 3 LEFT FUSE, RELAY MODULE LOW BEAM INDICATOR LAMP MULTI-FUNCTION DISPLAY PNK WIRE PNK/RED WIRE PWR-1 PWR-2 RBA-1 REAR FOG LAMP BUTTON REAR FOG LAMP INDICATOR LAMP RED WIRE RED/BLU WIRE RED/YEL WIRE SW 1 SW 2 SW 3 SW 4 VIO WIRE VIO/WHT WIRE YEL WIRE YEL/WHT WIRE

BLK/BRN WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DWS HL + DWS VL - ENGINE FUSE, RELAY MODULE FUSE 108 FUSE 110 FUSE 326 FUSE 329 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED LEFT FRONT LAMP UNIT LEFT HEADLAMP CONTROL UNIT LEFT HIGH BEAM LEFT LID SIGNALING LIGHTS ACTUATION MODULE FAN MOTOR LEFT LOW BEAM LEFT PARKING LIGHT, STANDING LIGHT, DAYTIME RUNNING LIGHT LEFT REAR LEVEL SENSOR POWER DISTRIBUTION SYSTEM RAIN/LIGHT SENSOR W/ ADDITIONAL FUNCTIONS RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT A-PILLAR FUSE BOX WHT/BLK WIRE YEL WIRE

BRN WIRE COMBINATION SWITCH COMPUTER DATA LINES SYSTEM FLEXRAY 1 BM FLEXRAY 1 BP GRN WIRE GRN/WHT WIRE HEADLAMP FLASHER/ HIGH BEAM SWITCH PNK WIRE RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT FRONT LAMP UNIT RIGHT HEADLAMP CONTROL UNIT RIGHT HIGH BEAM RIGHT LED SIGNALING LIGHTS ACTUATION MODULE FAN MOTOR RIGHT LOW BEAM RIGHT PARKING LIGHT, STANDING LIGHT, DAYTIME RUNNING LIGHT STEERING COLUMN MODULE CONTROL UNIT
