Mercedes-Benz GLC-class Coupe C253 (2016-2019) w/ remote trunk closing w/o remote trunk closing Wiring diagram
This page shows the only wiring diagram for the component.w/ remote trunk closing w/o remote trunk closing, which is found in the car Mercedes-Benz GLC-class Coupe C253 (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ remote trunk closing w/o remote trunk closing (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/PNK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER TRUNK LID/ LIFTGATE CONTROL BUTTON
FUSE 406
FUSE 413
FUSE 464
FUSE 465
FUSE 466
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
HDK Z
HFS
HOT AT ALL TIMES
HOT W/
LEFT FRONT DOOR CONTROL UNIT
LEFT TRUNK PARTITION HALL SENSOR
LEFT TRUNK RETRACTABLE PARTITION OBSTRUCTION HALL SENSOR
M+ (-)
ORG/BLU WIRE
PNK WIRE
QUIESCENT CURRENT CUTOUT RELAY ENERGIZED
REAR CONTROL UNIT (LEFT SIDE OF LUGGAGE COMPT)
REAR FUSE, RELAY MODULE
RED WIRE
RED/BLK WIRE
RIGHT TRUNK PARTITION HALL SENSOR
SIG
TRK GSCH R
TRUNK LID CONTROL UNIT
TRUNK LID EMERGENCY OPENING SWITCH
TRUNK LID RELEASE BUTTON
TRUNK LID/ LIFTGATE CONTROL ELECTRIC MOTOR
TRUNK LID/ LIFTGATE CONTROL POSITION SENSOR
TRUNK LID/LIFTGATE CONTROL DRIVE UNIT
TRUNK LID/LIFTGATE CONTROL WARNING BUZZER
TRUNK PARTITION MOTOR
TRUNK PARTITION SWITCH
W/ REMOTE TRUNK CLOSING W/O REMOTE TRUNK CLOSING
WHT WIRE
Go to component -> Trunk pull-down circuit, coupe (1 of 2) -> W/ REMOTE TRUNK CLOSING W/O REMOTE TRUNK CLOSING
