Mercedes-Benz GLC-class AMG X253 (2016-2019) trunk lid/ liftgate external operation switch Wiring diagrams
This page contains all the electrical diagrams for the component. trunk lid/ liftgate external operation switch, in which he is found in the car Mercedes-Benz GLC-class AMG X253 (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trunk lid/ liftgate external operation switch (1 of 2)
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAN B H
CAN B L RBA-1
COMPUTER DATA LINES SYSTEM
EXCEPT CONVERTIBLE
FUSE 302
FUSE 303
FUSE 406
FUSE 408
FUSE 465
FUSE 466
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
KRL L HL
KRL R HR
LEFT LUGGAGE COMPARTMENT LAMP
LEFT REAR FOOTWELL LAMP
LEFT TRUNK LID/ LIFTGATE AMBIENT LAMP, WARNING LAMP
PASSENGER-SIDE A-PILLAR FUSE BOX
PWR-1
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
RED WIRE
RIGHT LUGGAGE COMPARTMENT LAMP
RIGHT REAR FOOTWELL LAMP
RIGHT TRUNK LID/ LIFTGATE AMBIENT LAMP, WARNING LAMP
SIG
SIG HD
TRUNK LID/ LIFTGATE EXTERNAL OPERATION SWITCH
VIO WIRE
Go to component -> Courtesy lamps circuit (4 of 6) -> TRUNK LID/ LIFTGATE EXTERNAL OPERATION SWITCH
Wiring diagram trunk lid/ liftgate external operation switch (2 of 2)
30-2
BLK WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CAN B H
CAN B H RBA-1
CAN B L
CAN B L RBA-1
COMPUTER DATA LINES SYSTEM
DRIVER TRUNK LID/ LIFTGATE CONTROL BUTTON
ELECTRIC MOTOR
FRONT SAM CONTROL UNIT
FUSE 406
FUSE 464
FUSE 465
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
HALL SENSOR
HFS
HOT AT ALL TIMES
LEFT FRONT DOOR CONTROL UNIT
LOCK MOTOR
M+ (-)
MAIN CATCH SWITCH
NCA WIRE
POSITION SENSOR
PWR-1
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
RED WIRE
SAFETY CATCH SWITCH
SEPARATE TRUNK LID LOCK SWITCH
SIG
SIG (+) COC
SIG (1)
SIG (2)
SIG HD
TAILGATE CONTROL UNIT
TAILGATE LOCKING ELEMENT
TRUNK LID EMERGENCY OPENING SWITCH
TRUNK LID/ LIFTGATE CONTROL BUTTON
TRUNK LID/ LIFTGATE EXTERNAL OPERATION SWITCH
TRUNK LID/LIFTGATE CONTROL DRIVE UNIT
TRUNK LID/LIFTGATE CONTROL WARNING BUZZER
TRUNK LID/LIFTGATE LOCK
Go to component -> Trunk pull-down circuit, suv -> TRUNK LID/ LIFTGATE EXTERNAL OPERATION SWITCH
