Mercedes-Benz GLC-class AMG X253 (2016-2019) sliding roof hall sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.sliding roof hall sensor 2, which is found in the car Mercedes-Benz GLC-class AMG X253 (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sliding roof hall sensor 2 (1 of 1)
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
CAN B L RBA-1
COMPUTER DATA LINES SYSTEM
FRONT SAM CONTROL UNIT
FUSE 312
FUSE 317
HOT AT ALL TIMES
HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED
OVERHEAD CONTROL PANEL CONTROL UNIT
PASSENGER-SIDE A-PILLAR FUSE BOX
RED WIRE
RED/WHT WIRE
ROOF SWITCH
SLIDING ROOF CONTROL MODULE
SLIDING ROOF HALL SENSOR 1
SLIDING ROOF HALL SENSOR 2
SLIDING ROOF MOTOR
VIO WIRE
WHT WIRE
Go to component -> Power sliding roof circuit -> SLIDING ROOF HALL SENSOR 2
