Mercedes-Benz GLC-class AMG X253 (2016-2019) left front memory function switch left front memory 1 switch Wiring diagram

AUTOMATIC DIMMING MIRROR BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/YEL WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM DRIVER-SIDE POWER WINDOW, OUTSIDE MIRROR ADJUSTMENT SWITCH GROUP EL VL FUSE 406 GRN WIRE GRY WIRE GRY/WHT WIRE H NEIG SIG HORIZONTAL INCLINATION ADJUSTMENT ACTUATOR MOTOR HORIZONTAL INCLINATION ADJUSTMENT POTENTIOMETER HOT AT ALL TIMES LEFT BLIND SPOT ASSIST READINESS, WARNING INDICATOR LEFT FRONT DOOR CONTROL UNIT LEFT FRONT MEMORY 2 SWITCH LEFT FRONT MEMORY 3 SWITCH LEFT FRONT MEMORY FUNCTION SWITCH LEFT FRONT MEMORY 1 SWITCH LEFT FRONT SEAT ADJUSTMENT SWITCH GROUP LEFT OUTSIDE MIRROR LEFT OUTSIDE MIRROR ADJUSTMENT SWITCH LEFT OUTSIDE MIRROR AMBIENT LAMP LEFT OUTSIDE MIRROR TURN SIGNAL LAMP MIRROR HEATER NEIG HOR NEIG VER OUTSIDE MIRROR ADJUSTMENT SWITCH OUTSIDE MIRROR FOLD IN/ FOLD OUT ELECTRIC MIRROR OUTSIDE MIRROR FOLD-IN/ FOLD-OUT SWITCH REAR FUSE, RELAY MODULE RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT OUTSIDE MIRROR ADJUSTMENT SWITCH SPG ABBL SPG F SPG G TA B (+) TA W (+) V NEIG SIG VERTICAL INCLINATION ADJUSTMENT ACTUATOR MOTOR VERTICAL INCLINATION ADJUSTMENT POTENTIOMETER VIO WIRE WHT WIRE YEL WIRE YEL/GRN WIRE YEL/WHT WIRE
