Tire pressure monitoring circuit for Mercedes-Benz GLB-class X247 facelift (2023-2024)

BRN WIRE CAN HMI H CAN HMI L COMPUTER DATA LINES SYSTEM FUSE 167 HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL UNIT LEFT FRONT TIRE PRESSURE SENSOR LEFT REAR TIRE PRESSURE SENSOR RED/VIO WIRE RIGHT FRONT TIRE PRESSURE SENSOR RIGHT REAR TIRE PRESSURE SENSOR TIRE PRESSURE MONITOR CONTROL UNIT VEHICLE INTERIOR FUSE, RELAY MODULE VIO WIRE VIO/WHT WIRE
