Mercedes-Benz GLB-class X247 (2019-2023) flex e bm pnk flex e bp Wiring diagram
This page shows the only wiring diagram for the component.flex e bm pnk flex e bp, which is found in the car Mercedes-Benz GLB-class X247 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram flex e bm pnk flex e bp (1 of 1)
ACTIVE BRAKE ASSIST CONTROLLER UNIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
CAN B L
CAN HMI H
CAN HMI L
CAN PER H
CAN PER L
CAN-PER L PNK FLEX E BP WIRE
DRIVE UNIT CONTROL UNIT
ELECTRICAL POWER STEERING CONTROL UNIT
ELECTRONIC IGNITION SWITCH CONTROL UNIT
ELECTRONIC STABILITY PROGRAM CONTROL UNIT
FLEX E BM PNK FLEX E BP PNK FLEX E BP WIRE
FLEX E BM PNK FLEX E BP WIRE
FLEX E BP PNK FLEX E BM CAN-B H WIRE
FLEX-E BM
FLEX-E BP
FLEX-E BP PNK FLEX-E BM WIRE
GRN WIRE
GRN/WHT WIRE
LEFT OUTER REAR INTEGRATED RADAR SENSOR (W/ BLIND SPOT ASSIST)
PERIPHERALS CAN (CAN PER) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR
PNK FLEX-E BM WIRE
PNK FLEX-E BP WIRE
PNK WIRE
PNK/GRN WIRE
RIGHT OUTER REAR INTEGRATED RADAR SENSOR
SHORT, LONG-RANGE RADAR SENSOR
STEERING COLUMN MODULE CONTROL UNIT
VIO WIRE
VIO/WHT WIRE
W/ ACTIVE DISTANCE ASSIST DISTRONIC
W/ ACTIVE DISTANCE ASSIST DISTRONIC, COLLISION PREVENTION ASSIST
W/ COLLISION PREVENTION ASSIST
W/ DISTRONIC DISTANCE-PILOT
Go to component -> High/low bus circuit (2 of 6) -> FLEX E BM PNK FLEX E BP WIRE
