Ground distribution circuit for Mercedes-Benz GL-class X166 (2012-2016)
Ground distribution circuit (1 of 2)
& LANE KEEPING ASSIST),
3.5L
AUDIO/COMAND DISPLAY (IF EQUIPPED), BOOSTER BLOWER
BACKREST SWITCH (LOAD COMPARTMENT) (GL-CLASS),
BRN WIRE
CENTER REAR SEAT BELT BUCKLE SWITCH (GL-CLASS),
DIAGNOSTIC CONNECTOR, ELECTRONIC IGNITION SWITCH CONTROL UNIT,
ELECTRIC PARKING BRAKE SWITCH, INSTRUMENT CLUSTER,
ELECTRONIC BLOWER CONTROLLER (W/ COMFORT AUTOMATIC AIR CONDITIONING),
FRONT PASSENGER SEAT OCCUPIED
GLOVE BOX LAMP/ SWITCH
LEFT/RIGHT FRONT FOOTWELL LAMP,
MOBILE PHONE CONTACT PLATE (W/ COMPORT TELEPHONY),
POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR (CAN I), VEHICLE FLOOR
RIGHT REAR DISPLAY, DRIVER SIDE BAG SQUIB,
SAM CONTROL UNIT, MULTI-FUNCTION CAMERA (W/ TRAFFIC SIGN RECOGNITION
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT
WINDOW ANTI-PINCH PROTECTION CONTACT STRIP (GL-CLASS), REAR FUSE BOX (ML-CLASS)
Ground distribution circuit (2 of 2)
BATTERY SENSOR
BOOST PRESSURE CONTROL PRESSURE TRANSDUCER (3.0L TURBO DIESEL)
BRN WIRE
DIRECT SELECT INTELLIGENT SERVO MODULE (EXCEPT 3.0L TURBO DIESEL),
ELECTRICAL POWER STEERING CONTROL UNIT
ELECTRONIC STABILITY PROGRAM CONTROL UNIT
ENGINE COMPARTMENT FUSE, RELAY MODULE, ALARM SIREN (IF EQUIPPED),
FAN MOTOR
FOLDING BACKREST SWITCH,
FUEL PUMP CONTROL UNIT
FULLY INTEGRATED TRANSMISSION CONTROL UNIT (EXCEPT 3.0L TURBO DIESEL),
IGNITION COIL CYLINDERS 1, 2, 3, 4, 5, 6, 7, 8 (4.6L TURBO),
INTAKE PORT SHUTOFF ACTUATOR MOTOR
NCA WIRE
PTC HEATER BOOSTER (IF EQUIPPED)
REAR WINDOW HEATER
REAR WINDOW WAVE TRAP
RIGHT REAR BRAKE WEAR SENSOR
ROW BACKREST RELEASE UNIT (IF EQUIPPED),
SEAT BELT BUCKLE SWITCH (GL-CLASS),
TRAILER SOCKET
TRANSMISSION OIL AUXILIARY PUMP CONTROL UNIT (EXCEPT 3.0L TURBO DIESEL),
