Mercedes-Benz GL-class X166 (2012-2016) Data link connector circuit

Data link connector circuit

Car Wiring Diagrams for GL-class Mercedes-Benz X166 (2012-2016): Data link connector circuit

BRN WIRE COCKPIT CIRCUIT 30 FUSE BOX DIAGNOSTIC CONNECTOR ELECTRONIC IGNITION SWITCH CONTROL UNIT EMERGENCY CALL SYSTEM CONTROL UNIT FUSE 14 GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES RED/WHT WIRE
