Automatic a/c circuit, w/o thermotronic for Mercedes-Benz GL-class X166 (2012-2016)

11 12 SIG LI 6 7 SIG (+) AC HOUSING, AIR RECIRCULATION MODE BUTTON AUTOMATIC AIR CONDITIONING CONTROL, OPERATING UNIT BLK WIRE BLK/WHT WIRE BLOWER MOTOR BLOWER REGULATOR BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE CAN B H CAN-B L (5 TO 7 PINS NOT USED) 8 COMPUTER DATA LINES SYSTEM COOLANT CIRCULATION PUMP DEFOGGER SYSTEM ENGINE COMPARTMENT FUSE, RELAY MODULE EVAPORATOR TEMPERATURE SENSOR FRESH AIR/ AIR RECIRCULATION FLAP ACTUATOR MOTOR FUSE 19 FUSE 235 FUSE 237 GRN/BLU WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/YEL WIRE HIGH SIDE HOT AT ALL TIMES KMV SK (+) KOMP PWR 25 26 KOMP RV (-) LEFT BLENDING AIR FLAP ACTUATOR MOTOR LEFT CENTER AIR OUTLET FLAP ACTUATOR MOTOR LEFT DEFROSTER VENT FLAP ACTUATOR MOTOR LEFT FOOTWELL FLAP ACTUATOR MOTOR LIN DATA NCA WIRE PNK/WHT WIRE PTC HEATER BOOSTER (IF EQUIPPED) REAR BLEND AIR FLAP ACTUATOR MOTOR W/ CUT OFF FUNCTION RED WIRE RED/BLK WIRE REFRIGERANT COMPRESSOR REFRIGERANT PRESSURE SENSOR RIGHT BLENDING AIR FLAP ACTUATOR MOTOR SIG SIG (9, 10 PINS NOT USED) 11 SIG RE VDF VIO WIRE VIO/BLK WIRE VIO/WHT WIRE WHT WIRE WIPER PARK HEATER WIPER PARK POSITION HEATER RELAY YEL WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE

*** 3.0L TURBO DIESEL 3.0L TURBO DIESEL 4.6L TURBO, 3.5L 4.6L TURBO 3.5L AAV ACTIVATED CHARCOAL FILTER SHUTOFF VALVE BATTERY COMPARTMENT PREFUSE BOX BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/RED WIRE CHARGE AIR COOLER CIRCULATION PUMP CHARGE AIR TEMPERATURE SENSOR COMPUTER DATA LINES SYSTEM COOLANT TEMPERATURE SENSOR EA TANS ENGINE COMPARTMENT FUSE, RELAY MODULE ENGINE COMPARTMENT PREFUSE BOX ENGINE CONTROLS SYSTEM FAN MOTOR FAN MOTOR (BEHIND RADIATOR) FUSE 215 FUSE 216 FUSE 219 FUSE 257 FUSE 32 FUSE 53 FUSE 6 GRN WIRE GRN/BLU WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ CIRCUIT HOT W/ TURBO CHARGER RELAY ENERGIZED INTERIOR PREFUSE BOX INTERIOR TEMPERATURE SENSOR W/ INTEGRATED FAN LEFT CENTER AIR OUTLET SYMBOL ILLUMINATION LEFT FOOTWELL AIR OUTLET TEMPERATURE SENSOR LEFT FRONT SIDE AIR OUTLET SYMBOL ILLUMINATION LEFT REAR FOOTWELL LEFT SIDE AIR OUTLET TEMPERATURE SENSOR LUES ME-SFI CONTROL UNIT OUTSIDE TEMPERATURE SENSOR OVERHEAD CONTROL PANEL ELECTRONICS PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PNK/WHT WIRE PWM REAR AIR DISTRIBUTION FLAP ACTUATOR MOTOR REAR AIR DUCT AIR OUTLET TEMPERATURE SENSOR RED WIRE RED/BLK WIRE RED/BLU WIRE RIGHT CENTER AIR OUTLET SYMBOL ILLUMINATION RIGHT FOOTWELL AIR OUTLET TEMPERATURE SENSOR RIGHT FRONT SIDE AIR OUTLET SYMBOL ILLUMINATION RIGHT SIDE AIR OUTLET TEMPERATURE SENSOR SAM CONTROL UNIT SUN SENSOR TMOT UHI VEHICLE INTERIOR HUMIDITY/ TEMPERATURE SENSOR VIO WIRE VIO/BLK WIRE WHT WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/WHT WIRE
