Mercedes-Benz GL-class X166 (2012-2016) upstream temperature scr catalytic converter Wiring diagram
This page shows the only wiring diagram for the component.upstream temperature scr catalytic converter, which is found in the car Mercedes-Benz GL-class X166 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram upstream temperature scr catalytic converter (1 of 1)
ACCELERATOR PEDAL SENSOR
BATTERY COMPARTMENT PREFUSE BOX
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/PNK WIRE
BRN/WHT WIRE
CAN C H
CAN C L
CAN E H
CAN E L
CAN I H
CDI CONTROL UNIT (REAR OF RIGHT FRONT FENDER)
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CRASH PNK CAN 1 L WIRE
EFP
ENGINE COMPARTMENT FUSE, RELAY MODULE
FUSE 213
FUSE 215
FUSE 216
FUSE 217
FUSE 31
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
KJA
LUES
MRLY
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/WHT WIRE
RADIATOR SHUTTERS ACTUATOR
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
SAM CONTROL UNIT
SIG
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
UPSTREAM TEMPERATURE SCR CATALYTIC CONVERTER
UPWG
VIO/BLK WIRE
VIO/WHT WIRE
VSSAM
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo diesel (1 of 9) -> UPSTREAM TEMPERATURE SCR CATALYTIC CONVERTER
