Mercedes-Benz GL-class X166 (2012-2016) soot particulate sensor control unit Wiring diagrams
This page contains all the electrical diagrams for the component. soot particulate sensor control unit, in which he is found in the car Mercedes-Benz GL-class X166 (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
soot particulate sensor control unit wiring diagram (1 of 2)
3.0L TURBO DIESEL
3.5L
ADBLUE CONTROL UNIT
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
CAN I H
CAN I H PNK CAN I L WIRE
CAN I L
CAN-S H
CAN-S L
CDI CONTROL UNIT
FRONT PASSENGER SEAT CONTROL UNIT
GRY/BLK WIRE
GRY/WHT WIRE
GRY/YEL WIRE
LEFT NOX SENSOR CONTROL UNIT
LIN 13
LOWER CONTROL PANEL CONTROL UNIT
ME-SFI (ME) CONTROL UNIT
NOX SENSOR CONTROL UNIT DOWNSTREAM OF DIESEL PARTICULATE FILTER
NOX SENSOR CONTROL UNIT DOWNSTREAM OF SCR CATALYTIC CONVERTER
OFF-ROAD OPERATING PANEL CONTROL UNIT
OVER HEAD CONTROL PANEL CONTROL UNIT
PNK WIRE
PNK/WHT WIRE
POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR (CAN I)
REAR CONTROL UNIT
RIGHT FRONT DOOR CONTROL UNIT
RIGHT NOX SENSOR CONTROL UNIT
RIGHT REAR DOOR CONTROL UNIT
SAM CONTROL UNIT (RIGHT KICK PANEL)
SOOT PARTICULATE SENSOR CONTROL UNIT
STATIONARY HEATER UNIT
W/ ON-ROAD/OFF-ROAD PACKAGE, AIRMATIC
Go to component -> High/low bus circuit (5 of 5) -> SOOT PARTICULATE SENSOR CONTROL UNIT
soot particulate sensor control unit wiring diagram (2 of 2)
ADBLUE DELIVERY MODULE (EARLY PRODUCTION) (TOP OF ADBLUE TANK MODULE)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/PNK WIRE
BRN/RED WIRE
CAN CAN B H B L
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE WARNING LAMP INDICATOR
DELIVERY PUMP
ENGINE COMPARTMENT FUSE, RELAY MODULE
ENGINE DIAGNOSIS INDICATOR LAMP
FUEL LEVEL INDICATOR LAMP
FUEL RESERVE INDICATOR LAMP
FUSE 214
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/WHT WIRE
HEATING ELEMENT
INSTRUMENT CLUSTER
NOX SENSOR CONTROL UNIT DOWNSTREAM OF DIESEL PARTICULATE FILTER
NOX SENSOR CONTROL UNIT DOWNSTREAM OF SCR CATALYTIC CONVERTER
NOX SENSOR DOWNSTREAM OF DIESEL PARTICULATE FILTER
NOX SENSOR DOWNSTREAM OF SCR CATALYTIC CONVERTER
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/WHT WIRE
PNK/YEL WIRE
PREGLOW INDICATOR LAMP
PRESSURE SENSOR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RELAY ENERGIZED
SOOT PARTICULATE SENSOR
SOOT PARTICULATE SENSOR CONTROL UNIT
SWITCHOVER VALVE
VIO/WHT WIRE
WHT WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo diesel (5 of 9) -> SOOT PARTICULATE SENSOR CONTROL UNIT
