Mercedes-Benz GL-class X166 (2012-2016) soot particulate sensor wiring diagram
This page shows the only wiring diagram for the component.soot particulate sensor, which is found in the car Mercedes-Benz GL-class X166 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
soot particulate sensor wiring diagram (1 of 1)
ADBLUE DELIVERY MODULE (EARLY PRODUCTION) (TOP OF ADBLUE TANK MODULE)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/PNK WIRE
BRN/RED WIRE
CAN CAN B H B L
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE WARNING LAMP INDICATOR
DELIVERY PUMP
ENGINE COMPARTMENT FUSE, RELAY MODULE
ENGINE DIAGNOSIS INDICATOR LAMP
FUEL LEVEL INDICATOR LAMP
FUEL RESERVE INDICATOR LAMP
FUSE 214
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/WHT WIRE
HEATING ELEMENT
INSTRUMENT CLUSTER
NOX SENSOR CONTROL UNIT DOWNSTREAM OF DIESEL PARTICULATE FILTER
NOX SENSOR CONTROL UNIT DOWNSTREAM OF SCR CATALYTIC CONVERTER
NOX SENSOR DOWNSTREAM OF DIESEL PARTICULATE FILTER
NOX SENSOR DOWNSTREAM OF SCR CATALYTIC CONVERTER
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/WHT WIRE
PNK/YEL WIRE
PREGLOW INDICATOR LAMP
PRESSURE SENSOR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RELAY ENERGIZED
SOOT PARTICULATE SENSOR
SOOT PARTICULATE SENSOR CONTROL UNIT
SWITCHOVER VALVE
VIO/WHT WIRE
WHT WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo diesel (5 of 9) -> SOOT PARTICULATE SENSOR
