Mercedes-Benz GL-class X166 (2012-2016) right front running board courtesy lights Wiring diagram

BATTERY COMPARTMENT PREFUSE BOX BLK WIRE BLU WIRE BRN WIRE BRN/RED WIRE CAN B H CAN B L CENTRAL LOAD COMPARTMENT DOME LAMP COMPUTER DATA LINES SYSTEM FLAT WIRE FRONT PASSENGER SEAT CONTROL UNIT FUSE 253 FUSE 254 FUSE 52 FUSE 57 GRY WIRE GRY/BLK WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INTERIOR PREFUSE BOX LEFT FRONT FOOTWELL LAMP LEFT FRONT ILLUMINATED DOOR SILL MOLDING LEFT FRONT RUNNING BOARD COURTESY LIGHTS LEFT REAR FOOTWELL LAMP LEFT REAR RUNNING BOARD COURTESY LIGHTS LEFT RUNNING BOARD COURTESY LIGHTS MULTI-FUNCTION DISPLAY RAIN/LIGHT SENSOR RED/BLK WIRE RED/WHT WIRE RIGHT FRONT FOOTWELL LAMP RIGHT FRONT RUNNING BOARD COURTESY LIGHTS RIGHT REAR RUNNING BOARD COURTESY LIGHTS RIGHT RUNNING BOARD COURTESY LIGHTS TAILGATE AMBIENT LAMP TAILGATE EXTERNAL OPERATION SWITCH W/ INTERIOR LIGHTS PACKAGE YEL WIRE
