Mercedes-Benz GL-class X166 (2012-2016) rear fog light button Wiring diagram

49 L 49 R 57 L 57 R 58 L 58 R AMBIENT LAMP BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/YEL WIRE BSL L BSL R CAN B H CAN B L CENTER STOP LAMP COCKPIT CIRCUIT 30 FUSE BOX COMPUTER DATA LINES SYSTEM DISPLAY EXTERIOR LIGHTS SWITCH FRONT FOG LAMP BUTTON FUSE 114 FUSE 15 FUSE 250 GRN/BLK WIRE GRN/BLU WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE HAZARD WARNING SYSTEM BUTTON HEADLAMP RANGE CONTROLLER HOT AT ALL TIMES HOT W/ CIRCUIT 15 RELAY ENERGIZED INNER LEFT REAR LAMP UNIT INSTRUMENT CLUSTER INTERIOR PREFUSE BOX KZL L KZL R LDS 1 LDS 2 LDS 3 LEFT BACKUP LAMP LEFT FRONT DOOR CONTROL MODULE LEFT INSIDE TAILLIGHT LEFT LIFTGATE LICENSE PLATE LAMP LEFT OUTER TAILLIGHT LEFT OUTSIDE MIRROR LEFT REAR FOG LAMP LEFT REAR LAMP UNIT LEFT STOP LAMP LEFT TURN SIGNAL IND LEFT TURN SIGNAL LAMP LWR NCA WIRE NIGHT VIEW ASSIST BUTTON NSI L ORG/ WIRE REAR FOG LIGHT BUTTON REAR FUSE BOX RED/BLK WIRE RED/WHT WIRE RFL L RFL R RIGHT LIFTGATE LICENSE PLATE LAMP RIGHT TURN SIGNAL IND SAM CONTROL MODULE SL L SWITCH ILLUMINATION TURN SIGNAL LAMP UPPER CONTROL PANEL CONTROL UNIT VIO/BLK WIRE VIO/WHT WIRE W/ XENON HEADLAMP W/O XENON HEADLAMP WHT WIRE WHT/BLU WIRE
