Mercedes-Benz GL-class X166 (2012-2016) left front axle damping valve unit Wiring diagram
This page shows the only wiring diagram for the component.left front axle damping valve unit, which is found in the car Mercedes-Benz GL-class X166 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front axle damping valve unit (1 of 1)
ABLV
AIRMATIC COMPRESSOR UNIT
AIRMATIC CONTROL UNIT
AIRMATIC PRESSURE REDUCTION VALVE
AIRMATIC RELAY
BATTERY COMPARTMENT PREFUSE BOX
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
COMPRESSOR MOTOR
COMPUTER DATA LINES SYSTEM
DVV
ENGINE COMPARTMENT FUSE, RELAY MODULE
ENGINE COMPARTMENT PREFUSE BOX
FUSE 2
FUSE 238
FUSE 5
FUSE 62
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/ CIRCUIT
LEFT FRONT AXLE DAMPING VALVE UNIT
LEFT FRONT LEVEL SENSOR
MULTI FUSE 1
NCA WIRE
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PNK/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
REL (+) SIG
REL VERS
RIGHT FRONT AXLE DAMPING VALVE UNIT
RIGHT FRONT LEVEL SENSOR
SIG
SOLENOID
VALVE 1
VALVE 2
VIO WIRE
W/ ADS
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Airmatic control circuit (1 of 2) -> LEFT FRONT AXLE DAMPING VALVE UNIT
