Mercedes-Benz GL-class X166 (2012-2016) front passenger massage function control unit Wiring diagram
This page shows the only wiring diagram for the component.front passenger massage function control unit, which is found in the car Mercedes-Benz GL-class X166 (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger massage function control unit (1 of 1)
BATTERY COMPARTMENT PREFUSE BOX
BLK/WHT WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FDS L (-)
FFRBEL
FRONT PASSENGER MASSAGE FUNCTION CONTROL UNIT
FRONT PASSENGER MULTICONTOUR SEAT CONTROL UNIT
FRONT PASSENGER SEAT BACKREST INCLINATION ADJUSTMENT MOTOR, HALL SENSOR
FRONT PASSENGER SEAT CONTROL UNIT
FRONT PASSENGER SEAT HEAD RESTRAINT ADJUSTMENT MOTOR, HALL SENSOR
FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT
FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
FRONT PASSENGER SEAT LUMBAR SUPPORT PNEUMATIC PUMP
FUSE 103
FUSE 129
FUSE 52
GRN/BLK WIRE
GRN/BLU WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ CIRCUIT
K MOT
KS HS SIG
L HS (-)
L MOT (-)
NCA WIRE
PNK WIRE
REAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SEATS SYSTEM
SIG
VIO WIRE
W/ MASSAGE FUNCTION W/O MASSAGE FUNCTION
WHT WIRE
YEL WIRE
Go to component -> Passenger"s memory seat circuit (1 of 2) -> FRONT PASSENGER MASSAGE FUNCTION CONTROL UNIT
