Tire pressure monitoring circuit for Mercedes-Benz E-class W214/S214 (2023-2024)
Tire pressure monitoring circuit
BRN WIRE
CAN HMI H
CAN HMI L
COMPUTER DATA LINES SYSTEM
FUSE 467
HOT W/ BATTERY DISCONNECT SWITCH RELAY ENERGIZED
INSTRUMENT CLUSTER CONTROL UNIT
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
REAR FUSE, RELAY MODULE
RED/GRN WIRE
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
TIRE PRESSURE MONITOR CONTROL UNIT
VIO WIRE
VIO/WHT WIRE
