Panoramic roof circuit for Mercedes-Benz E-class W214/S214 (2023-2024)
Panoramic roof circuit
BLK WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
COUPE
FUSE 309
FUSE 316
HOT AT ALL TIMES
MOT GND/(+)
OVERHEAD CONTROL PANEL CONTROL UNIT
PANORAMIC SLIDING ROOF ROLLER SUN BLIND DRIVE UNIT
PANORAMIC SLIDING SUNROOF CONTROL MODULE
PASSENGER-SIDE A-PILLAR FUSE BOX
RED/WHT WIRE
SEDAN WAGON
SENS
SENS 1
SENS 2
SENS GND
