Rear heated seats circuit for Mercedes-Benz E-class W214/S214 (2023-2024)
Rear heated seats circuit
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE FUSE, RELAY MODULE
FUSE 214
FUSE 301
FUSE 451
HOT W/ BATTERY DISCONNECT SWITCH RELAY ENERGIZED
LEFT REAR BACKREST HEATER CUSHION
LEFT REAR DOOR CONTROL UNIT
LEFT REAR SEAT SITTING SURFACE HEATED CUSHION
NCA WIRE
PASSENGER-SIDE A-PILLAR FUSE BOX
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
REAR SEAT HEATERS CONTROL UNIT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR BACKREST HEATER PAD
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR SEAT SITTING SURFACE HEATED CUSHION
