Rear head restraint circuit, sedan for Mercedes-Benz E-class W214/S214 (2023-2024)
Rear head restraint circuit, sedan (1 of 2)
BLK/BLU WIRE
BLK/GRN WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FUSE 476
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT REAR BACKREST INCLINATION SWITCH
LEFT REAR BACKREST LOCK SWITCH
ORG/ WIRE
ORG/BLU WIRE
ORG/GRN WIRE
PNK WIRE
PNK/GRN WIRE
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
RED/BLK WIRE
RIGHT REAR BACKREST INCLINATION SWITCH
RIGHT REAR BACKREST LOCK SWITCH
SEDAN
SIG
WAGON
Rear head restraint circuit, sedan (2 of 2)
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FRONT SAM CONTROL UNIT
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/YEL WIRE
LEFT LUGGAGE COMPARTMENT REAR BACKREST RELEASE BUTTON
LEFT REAR PASSENGER COMPARTMENT HEAD RESTRAINT RELEASE ACTUATOR
ORG/GRN WIRE
RIGHT LUGGAGE COMPARTMENT REAR BACKREST RELEASE BUTTON
RIGHT REAR BACKREST LOCK SWITCH
RIGHT REAR PASSENGER COMPARTMENT HEAD RESTRAINT RELEASE ACTUATOR
SIG
WAGON
