Front ventilation & heated seat circuit, wagon for Mercedes-Benz E-class W214/S214 (2023-2024)

Front ventilation & heated seat circuit, wagon (1 of 3)

E-class Mercedes-Benz W214/S214 (2023-2024): Front ventilation & heated seat circuit, wagon (1 of 3)

Get access

BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM DRIVER SEAT CONTROL UNIT DRIVER-SIDE FUSE, RELAY MODULE FUSE 203 FUSE 302 FUSE 303 FUSE 304 HOT W/ BATTERY DISCONNECT SWITCH RELAY ENERGIZED LEFT FRONT DOOR CONTROL UNIT LEFT FRONT SEAT BACKREST HEATER PAD LEFT FRONT SEAT BACKREST SIDE BOLSTER HEATER PAD LEFT FRONT SEAT CLIMATE CONTROL SWITCH GROUP LEFT FRONT SEAT CUSHION HEATER PAD LEFT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD MOT (+) MOT GND MOT GND/(+) NCA WIRE PASSENGER-SIDE A-PILLAR FUSE BOX RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SIG VIO WIRE

Front ventilation & heated seat circuit, wagon (2 of 3)

E-class Mercedes-Benz W214/S214 (2023-2024): Front ventilation & heated seat circuit, wagon (2 of 3)

Get access

BRN WIRE BRN/GRN WIRE BRN/YEL WIRE LEFT FRONT BACKREST SEAT VENTILATION MOTORS LEFT FRONT SEAT ADJUSTMENT SWITCH GROUP LEFT FRONT SEAT CUSHION SEAT VENTILATION MOTORS NCA WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BACKREST SEAT VENTILATION MOTORS RIGHT FRONT SEAT CLIMATE CONTROL SWITCH GROUP RIGHT FRONT SEAT CUSHION SEAT VENTILATION MOTORS VIO WIRE

Front ventilation & heated seat circuit, wagon (3 of 3)

E-class Mercedes-Benz W214/S214 (2023-2024): Front ventilation & heated seat circuit, wagon (3 of 3)

Get access

BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM FRONT PASSENGER SEAT CONTROL UNIT MOT (+) MOT GND NCA WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR CONTROL UNIT RIGHT FRONT SEAT ADJUSTMENT SWITCH GROUP RIGHT FRONT SEAT BACKREST HEATER PAD RIGHT FRONT SEAT CUSHION HEATER PAD RIGHT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD SIG VIO WIRE
