Backup lamps circuit, sedan for Mercedes-Benz E-class W214/S214 (2023-2024)
Backup lamps circuit, sedan
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
ELECTRONIC IGNITION SWITCH CONTROL UNIT
FULLY INTEGRATED TRANSMISSION CONTROL UNIT
FUSE 477
HOT W/ BATTERY DISCONNECT SWITCH RELAY ENERGIZED
LEFT BACKUP LAMP
LEFT REAR LAMP UNIT
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
RED/GRY WIRE
RED/YEL WIRE
RIGHT BACKUP LAMP
RIGHT REAR LAMP UNIT
SIG (+) HECKL
SIG HECKR
VIO/WHT WIRE
